Weintek MT8051iE

Overview

Elevate your industrial control systems with the Weintek MT8051iE, a meticulously engineered 4.3-inch Human Machine Interface. This compact powerhouse delivers an exceptional user experience, combining a vibrant display with comprehensive connectivity options. Perfectly suited for demanding automation environments, the MT8051iE provides an intuitive interface for monitoring and controlling diverse machinery. Its robust design ensures reliable performance in even the most challenging operational settings, making it an indispensable component for optimizing efficiency and oversight.

Designed with the modern industrial landscape in mind, this HMI facilitates seamless integration into existing setups. Whether you're a seasoned system integrator, an original equipment manufacturer, or a control panel designer, the MT8051iE offers a streamlined solution for bridging the gap between operators and complex machinery. Configure with ease using the renowned EasyBuilder Pro software, unlocking a world of customization and sophisticated control functionalities.

Key Features

• Brilliant 4.3" TFT LCD: Experience crisp visuals with a 480x272 resolution and an impressive 16.7 million colors, all illuminated by an enduring LED backlight for superior clarity.
• Responsive Resistive Touch: Enjoy precise and reliable operator interaction with a durable 4-wire resistive touchscreen, engineered for consistent performance.
• Advanced Ethernet Connectivity: Integrate effortlessly into network architectures with 10/100 Mbps Ethernet, enabling both local and remote access capabilities.
• Flexible Serial Communication: Benefit from extensive PLC compatibility thanks to dedicated RS-232/RS-485 serial ports, supporting a wide array of industrial protocols.
• Convenient USB Host Port: Expand your peripheral options and simplify data logging tasks with an accessible USB 2.0 host port.
• Integrated Real-Time Clock (RTC): Ensure accurate time-stamping for all your operational data, critical for analysis and regulatory compliance.
• Silent Fanless Operation: Maintain a quiet and low-maintenance environment with a fanless cooling design, enhancing reliability and reducing downtime.
• Industrial-Grade Front Panel: Confidence in harsh conditions is assured with a NEMA4/IP65 rated front panel, providing excellent protection against dust and water ingress.

Technical Specifications

• Model: MT8051iE
• Display Size: 4.3 inches
• Resolution: 480 x 272 pixels
• Touch Panel: 4-wire resistive
• Processor: 32-bit RISC Cortex-A8 600MHz
• Memory: 128 MB Flash / 128 MB RAM
• Ethernet: 1 x 10/100 Base-T
• Serial Ports:
  • COM1: RS-232/RS-485 2W/4W
  • COM3: RS-485 2W
• USB Host: 1 x USB 2.0
• Power Input: 24V DC ±20%
• Power Consumption: 450 mA @ 24VDC
• Dimensions (WxHxD): 128 x 102 x 32 mm
• Panel Cutout: 119 x 93 mm
• Operating Temperature: 0°C to +45°C
• Mounting: Panel mount
• Protection Structure: NEMA4 / IP65 Compliant Front Panel
• Certifications: CE, cULus Listed
• Software: EasyBuilder Pro V6.06.02 or later

Applications

• Precision control in Industrial Automation Systems
• Operator interfacing for PLC-Based Control Panels
• Bespoke interfaces for OEM Machine Applications
• Visualizing and recording data in SCADA & Data Logging Displays
• General manufacturing and process control environments

Why Choose This Model?

The Weintek MT8051iE stands out as a superior choice for several compelling reasons. Its compact form factor is specifically engineered for installations where space is a premium, allowing for seamless integration into even the most constrained control cabinets. Beyond its space-saving design, this HMI boasts a rugged industrial construction, guaranteeing longevity and consistent performance in demanding operational environments. The MT8051iE offers unparalleled communication flexibility, featuring an array of ports that ensure broad compatibility with diverse programmable logic controllers and peripheral devices. Furthermore, the complementary EasyBuilder Pro software provides an intuitive platform for rapid application development and deployment, making the setup and configuration process straightforward and efficient. Opt for the MT8051iE for a blend of compact design, robust performance, and user-friendly integration.

Order Now

This exceptional industrial HMI is currently in stock and readily available for global shipping. Secure your Weintek MT8051iE today to enhance your automation capabilities and streamline your operational control. Experience the perfect synergy of advanced technology and reliable performance.
