Schneider Electric TM241CE40R

Overview

Elevate your industrial automation capabilities with the Schneider Electric TM241CE40R, a sophisticated yet compact logic controller engineered for unparalleled control. Part of the renowned Modicon M241 series, this Programmable Logic Controller (PLC) is meticulously designed to orchestrate intricate machine functions with precision and reliability. Boasting 40 integrated input/output points, including robust relay outputs, and a comprehensive suite of communication interfaces, the TM241CE40R stands as an ideal solution for Original Equipment Manufacturers (OEMs) and diverse industrial environments demanding superior flexibility, high-end performance, and seamless connectivity. Revolutionize your control systems with this versatile and powerful automation brain.

Key Features

• All-Inclusive I/O Configuration: Outfitted with 24 crystal-clear 24V DC digital inputs and 16 powerful relay outputs, each capable of handling up to 2 Amperes, ensuring direct and efficient control over various actuators and devices.
• Integrated Multi-Protocol Communication Suite:
• Ethernet Connectivity: A single Ethernet port supporting Modbus TCP, FTP, and HTTP for streamlined network integration and remote access.
• Serial Interface: A versatile serial port (RS232/RS485) to accommodate a broad spectrum of legacy and modern communication needs.
• CANopen Integration: Dedicated CANopen port functioning as both Master and Slave, perfect for complex distributed control systems.
• USB Mini-B: Convenient USB Mini-B port for effortless programming and firmware updates.
• Integrated Real-Time Clock: A built-in timekeeping mechanism for precise event scheduling, data logging, and accurate timestamping of critical operations.
• High-Velocity Processing Unit: Driven by a high-performance 32-bit CPU, guaranteeing lightning-fast logic execution and expeditious response times for critical applications.
• Modular Expandability: Fully compatible with Schneider Electric TM3 I/O expansion modules, allowing for future system growth and tailored customization to meet evolving requirements.
• Intuitive Programming Environment: Programmed effortlessly using EcoStruxure Machine Expert software (formerly SoMachine), a comprehensive and user-friendly platform that simplifies development and deployment.

Technical Specifications

• Model Designation: TM241CE40R
• Product Series: Modicon M241
• Power Requirements: 24V DC
• Digital Input Count: 24 (operating at 24V DC)
• Relay Output Configuration: 16 relay outputs, each with a maximum capacity of 2 A
• Processor Speed: 50 MHz
• Memory Architecture:
• Program Memory: 640 kB for extensive application code.
• RAM: 128 kB for dynamic data and operational variables.
• Backup Memory: 16 kB, diligently supported by a battery to safeguard critical data during power interruptions.
• Ingress Protection (IP) Rating: IP20
• Operational Temperature Range: 0°C to +55°C
• Mounting Method: Standard DIN rail mounting for convenient installation.
• Physical Dimensions (W x H x D): 150 mm x 90 mm x 70 mm
• Approximate Mass: 0.45 kg

Applications

The Schneider Electric TM241CE40R is a truly versatile controller, perfectly suited for a wide array of demanding applications across various industries:

• Sophisticated Industrial Machinery: Provides precise control for complex conveyor systems, high-speed packaging lines, and intricate processing equipment.
• Advanced Building Management Systems: Expertly manages and optimizes building functions, including intelligent lighting control, efficient HVAC systems, and comprehensive facility automation.
• OEM Solution Integration: Serves as an ideal, compact control engine for original equipment manufacturers whose machinery demands reliable relay switching and advanced automation.
• Seamless IIoT System Integration: Effortlessly integrates into modern Industrial Internet of Things (IIoT) architectures, facilitating data exchange and enhancing connectivity within smart factory ecosystems.

Why Choose This Model?

• Embedded Relay Outputs: Direct and efficient control of contactors, solenoids, and other actuators, reducing wiring complexity and component count.
• Versatile Communication Options: Offers an exceptional range of connectivity with Ethernet, CANopen, and serial ports, ensuring compatibility with diverse network infrastructures.
• Future-Proof Expandability & Scalability: Seamless integration with TM3 I/O modules allows your system to grow and adapt to future operational demands without replacing the core controller.
• Unwavering Performance & Reliability: Engineered to deliver consistent and dependable performance in the most challenging and varied automation scenarios.

Order Now

Secure your Schneider Electric TM241CE40R today and propel your automation projects forward. Benefit from swift shipping and worldwide delivery options to get this essential controller into your hands without delay.
