Siemens 6AV2124-0QC02-0AX2

Overview

The Siemens SIMATIC KTP700 Basic PN (6AV2124-0QC02-0AX2) is an essential 7-inch Human Machine Interface (HMI) meticulously engineered for optimal performance in diverse industrial automation environments. As part of the renowned SIMATIC KTP Basic line, this HMI combines a vibrant 7-inch TFT touch display with seamless PROFINET capabilities, making it the perfect solution for straightforward visualization and intuitive operation within small to medium-sized control systems. Designed with user flexibility in mind, it incorporates six tactile function keys, offering multiple input methods within a compact and robust form factor. This device significantly enhances operational efficiency by providing clear data representation and reliable control, streamlining processes across various applications.

Key Features

• Vibrant 7-inch Widescreen TFT Touch Display: Experience crisp visuals and responsive interaction on an 800 x 480-pixel screen, ensuring clear data presentation.
• Six Configurable Function Keys: Gain enhanced operational flexibility with dedicated physical buttons for critical and frequently used functions.
• PROFINET/Ethernet Communication: Benefit from high-speed, reliable data exchange and effortless integration into existing network infrastructures.
• Seamless TIA Portal Integration: Configure and program your HMI efficiently with WinCC Basic within the intuitive TIA Portal environment.
• Robust Industrial Design: Engineered for durability, this unit features fanless operation and an IP65 front protection rating, ensuring long-term reliability in demanding conditions.
• Compact and Space-Saving: Its optimized design allows for easy and efficient integration into control panels, saving valuable space.

Technical Specifications

• Siemens Code: 6AV2124-0QC02-0AX2
• Series: SIMATIC HMI Basic
• Display Size: 7” widescreen (16:9 aspect ratio)
• Resolution: 800 × 480 pixels
• Color Depth: 65,536 colors with LED backlighting
• Touchscreen Type: Resistive
• Function Keys: 6
• Communication Interface: 1× PROFINET (Ethernet), 1× USB
• Rated Voltage: 24 V DC
• Power Consumption: Approximately 4.8 W
• Protection Rating: IP65 (front panel), IP20 (rear)
• Operating Temperature: 0 °C to +50 °C
• Software Compatibility: TIA Portal, WinCC Basic V13 or higher

Applications

• Small to Medium-Scale Machinery: Ideal for controlling and monitoring compact machines and equipment where space is at a premium.
• Packaging and Material Handling Systems: Provides intuitive operator control, optimizing processes in automated packaging lines and material transport.
• OEM Machine Panels: A cost-effective and reliable HMI solution for original equipment manufacturers to integrate into their standard product offerings.
• Basic Plant Automation: Enhances the user interface in processes requiring essential visualization and operational control.
• Food & Beverage Processing: Suitable for environments requiring clear displays and easy cleaning, thanks to its robust front panel protection.
• Water Treatment Facilities: Offers reliable monitoring and control for various stages of water purification and distribution.

Why Choose This Model?

• Enhanced Usability: The crystal-clear 7-inch touch display combined with physical function keys provides an intuitive and flexible operator experience, reducing learning curves and improving efficiency.
• Unmatched Reliability: Built to Siemens' stringent quality standards, this HMI ensures long-term, stable performance even in demanding industrial conditions, backed by fanless operation and robust construction.
• Seamless Integration: Leverage the full power of Siemens' TIA Portal for straightforward configuration and programming, ensuring rapid deployment and compatibility with other SIMATIC components.
• Superior Connectivity: With PROFINET communication, enjoy high-speed, real-time data exchange, crucial for responsive control and seamless network integration.
• Cost-Effective Solution: Achieve advanced visualization and control functionalities without compromising your budget, making it an excellent investment for basic to advanced automation tasks.
• Compact and Durable: Its space-saving design and high protection ratings (IP65 front) allow for versatile mounting and reliable operation in a wide array of industrial environments.

Order Now

Elevate your control systems with the Siemens SIMATIC KTP700 Basic PN HMI (6AV2124-0QC02-0AX2). This powerful, reliable, and user-friendly interface is specifically designed to optimize basic industrial control tasks, providing clarity, precision, and efficiency. Invest in Siemens quality and enhance your operational output today.
