Siemens 6ED1055-4MH08-0BA1

Overview

Elevate your automation capabilities with the Siemens 6ED1055-4MH08-0BA1 LOGO! DM8 24R Expansion Module. This essential component seamlessly integrates with your existing LOGO! 8 logic controllers, significantly expanding their input and output functionality. Designed for precision and reliability, the 6ED1055-4MH08-0BA1 offers 4 robust digital inputs and 4 versatile relay outputs, operating efficiently on a 24V DC power supply. Its compact, IP20-rated design makes it ideal for a wide array of applications, from sophisticated building management systems and HVAC control to light industrial automation tasks. Experience enhanced flexibility and control, empowering your systems with greater adaptability and performance.

Key Features

• Expanded I/O Capacity: Provides 4 digital inputs (24V DC) and 4 relay outputs, significantly boosting your LOGO! 8 system's capabilities.
• High-Current Relay Outputs: Each relay output boasts a maximum switching capacity of 10A, allowing direct control of substantial AC/DC loads.
• Seamless LOGO! 8 Integration: Specifically designed as an expansion module for seamless compatibility and easy integration with LOGO! 8 base modules.
• Robust Protection: Features an IP20 protection class, ensuring reliable operation in typical industrial and commercial environments.
• Flexible Mounting: Din rail mounting capability offers quick and secure installation within control cabinets and enclosures.
• Screw Terminal Connections: Ensures straightforward and secure wiring for both inputs and outputs.
• Wide Operating Temperature: Reliably functions across a temperature range of 0°C to +55°C, suitable for various demanding applications.

Technical Specifications

• Part Number: 6ED1055-4MH08-0BA1
• Series: LOGO! 8
• Module Type: Expansion Module
• Digital Inputs: 4 (24V DC)
• Relay Outputs: 4 (AC/DC switching capability)
• Output Current: Max. 10A per relay
• Input Voltage Range: 20.4 to 28.8 V DC
• Relay Contact Rating: 250V AC / 30V DC, 10A max
• Connection Type: Screw terminals
• Mounting: DIN rail
• Protection Class: IP20
• Dimensions (W x H x D): Approx. 72 x 90 x 55 mm
• Weight: Approx. 160 g
• Operating Temperature: 0°C to +55°C
• Certifications: CE, UL, RoHS compliant
• Response Time: Fast input and output switching for precise control.

Applications

• Smart Building and HVAC Systems: Enhance control over lighting, access, ventilation, and climate regulation in commercial and residential buildings.
• Water Management and Pump Control: Automate water level monitoring, pump activation, and fluid transfer processes for increased efficiency and reliability.
• Energy Efficiency Solutions: Implement advanced energy-saving strategies in building management and industrial processes, reducing operational costs.
• Compact Machine Automation: Ideal for small to medium-sized machinery requiring precise control and extended I/O capabilities.
• Traffic Light and Barrier Systems: Provides robust control for traffic management solutions and automated barrier systems.
• Environmental Monitoring: Integrate with sensors for basic environmental data acquisition and automated responses.

Why Choose This Model?

• Unmatched Flexibility: Effortlessly expand your LOGO! 8 system's I/O without needing an entirely new controller, saving time and resources.
• Control High-Power Loads: The high-capacity relay outputs (10A) allow for direct control of a wider range of devices and machinery, simplifying wiring and reducing the need for intermediate relays.
• Space-Efficient Design: Its slim, compact form factor ensures it integrates seamlessly into existing control cabinets, maximizing space utilization.
• Trusted Siemens Reliability: Benefit from Siemens' renowned engineering and manufacturing quality, ensuring long-term stable performance and durability in demanding industrial environments.
• Simplified Installation: Designed for quick and easy DIN rail mounting with user-friendly screw terminals, reducing installation time and complexity.
• Global Compliance: With CE, UL, and RoHS certifications, the 6ED1055-4MH08-0BA1 meets international standards, making it suitable for worldwide deployment.

Order Now

Ready to enhance your automation projects? The Siemens 6ED1055-4MH08-0BA1 LOGO! DM8 24R Expansion Module is in stock and available for immediate dispatch. Take advantage of its advanced features and reliable performance to optimize your control systems. We offer fast and secure global delivery to ensure your project stays on schedule. Explore our extensive range of Siemens LOGO! products and other automation solutions today to find everything you need.
