Schneider Electric TM3XTRA1

Overview

Unlock new levels of control and flexibility within your automation ecosystem with the Schneider Electric TM3XTRA1 industrial auxiliary relay. This essential component seamlessly integrates with your existing Modicon TM3 expansion modules, providing a critical interface for complex control logic. Meticulously engineered with one normally open (NO) and one normally closed (NC) contact, the TM3XTRA1 is purpose-built to broaden your system's input/output capabilities, ensuring robust and responsive operation across a spectrum of industrial applications. Experience unwavering reliability and precision in your control strategies with this indispensable addition.

Key Features

• Precision Contact Configuration: Equipped with a versatile 1 NO + 1 NC contact arrangement, offering dual control options for diverse operational demands.
• Robust Electromechanical Design: Built for endurance, this relay provides dependable mechanical switching action under demanding industrial conditions.
• Optimized Voltage Control: Operates efficiently with a 24V DC control voltage, ensuring compatibility with standard industrial control power supplies.
• Generous Current Rating: Capable of handling 2 A at 250V AC, suitable for a variety of switching tasks.
• Seamless Modicon TM3 Integration: Specifically designed for effortless mounting and compatibility with Modicon TM3 series modules, streamlining system expansion.
• Extended Service Life: Engineered for exceptional mechanical and electrical longevity, promising years of consistent performance.

Technical Specifications

• Model Identifier: TM3XTRA1
• Product Ecosystem: Modicon TM3 Series
• Contact Configuration: 1 NO (Normally Open) + 1 NC (Normally Closed)
• Control Circuit Voltage: 24V DC
• Rated Operational Current: 2 A (AC-15), 2 A (DC-13)
• Installation Method: Convenient plug-in module for rapid deployment and integration.
• Mechanical Durability: An impressive 10,000,000 switching operations, guaranteeing mechanical endurance.
• Electrical Durability: Rated for 100,000 switching operations, ensuring prolonged electrical performance.
• Operational Temperature Range: Resilient in environments from -25°C to +55°C.
• Storage Conditions: Withstands temperatures ranging from -40°C to +85°C.
• Physical Dimensions (W x H x D): Compact at 22.5 mm x 90 mm x 58 mm.
• Weight (Approximate): A lightweight 0.05 kg.
• Compliance and Certifications: Adheres to global standards including UL, CSA, and CE.

Applications

• Advanced Control Panel Augmentation: Ideal for augmenting the I/O capacity within sophisticated industrial control panels, enabling broader system management.
• Automated Machinery Operations: Furnishes critical auxiliary relay functions for diverse machine automation sequences, enhancing operational precision.
• Specialized Industrial Equipment: Provides supplementary contacts for bespoke industrial machinery, meeting specific operational requirements.
• Integrated Building Management Systems: Perfectly suited for the meticulous control of lighting circuits and HVAC system relays within modern building infrastructure.

Why Choose This Model?

The Schneider Electric TM3XTRA1 stands out as a prime choice for professionals seeking to optimize their automation architecture. Its streamlined plug-and-play design ensures straightforward integration into existing Modicon TM3 systems, minimizing installation time and complexity. More than just easy to install, this relay embodies a balance of compact footprint and unwavering reliability, delivering sustained, high-performance operation without occupying excessive panel space. With support for both normally open and normally closed configurations, it offers unparalleled versatility in control logic deployment. Furthermore, its engineering for exceptional mechanical and electrical durability translates into a cost-effective, long-term solution that consistently performs under rigorous industrial demands, safeguarding your investments and enhancing operational continuity.

Order Now

Ready to elevate your industrial control capabilities? The Schneider Electric TM3XTRA1 auxiliary relay is available for immediate dispatch, with efficient worldwide shipping options to ensure your project stays on schedule. Explore our comprehensive collection of Schneider Electric Modicon TM3 Expansion I/O Modules to discover more components designed for seamless integration and optimal performance. Additionally, delve into our extensive range of Schneider Electric PLCs to find scalable, adaptable, and dependable automation solutions crafted for the most demanding industrial environments.
