Schneider Electric TM241CE24R

Overview

Introducing the Schneider Electric TM241CE24R, a cornerstone of the Modicon M241 range, engineered for today's demanding automation environments. This advanced logic controller seamlessly integrates 24 input/output (I/O) points, robust relay outputs, and essential Ethernet connectivity, providing a powerful backbone for intelligent machine control. Designed with an emphasis on both performance and adaptability, the TM241CE24R delivers flexible and scalable solutions, empowering industrial systems to operate with heightened precision and efficiency.

Key Features

• Versatile I/O Configuration:
• Discrete Inputs: 14 total, including 8 high-speed inputs compliant with IEC 61131-2 Type 1 for rapid signal detection.
• Discrete Outputs: A total of 10 outputs, comprising 6 resilient relay outputs alongside 4 lightning-fast transistor outputs.
• Advanced Communication Interfaces:
• Ethernet Port: Facilitates seamless integration into network architectures for remote management and data exchange.
• Serial Ports: Two adaptable serial line ports (RS232/RS485) offer broad compatibility for diverse communication protocols.
• USB Port: A convenient Mini-B USB 2.0 interface streamlines programming and configuration tasks.
• Robust Memory & Storage:
• Program Memory: Generous 8 MB dedicated for intricate user programs.
• Data Storage: 128 MB of integrated flash memory ensures secure data retention even during power interruptions.
• SD Card Slot: Expandable storage up to 16 GB via SD cards for extensive data logging and backup.
• Exceptional Processing Performance:
• Rapid Execution: Achieves an impressive 0.3 ms for time-critical event and periodic tasks, and 0.7 ms for other instructions.
• Real-Time Clock: An integrated, battery-backed real-time clock ensures accurate timekeeping for all operations.
• Precision Positioning Functions:
• Pulse Train Output (PTO): Features 4 channels with a positioning frequency reaching up to 100 kHz for precise motion control.
• High-Speed Counting (HSC): 4 dedicated fast inputs support frequencies up to 200 kHz for accurate event counting.

Technical Specifications

• Model Designation: TM241CE24R
• Product Series: Modicon M241
• Supply Voltage Range: 100–240 V AC
• Discrete Input Voltage: 24 V DC
• Discrete Output Voltage:
• Relay Outputs: 5–125 V DC; 5–250 V AC
• Transistor Outputs: 24 V DC
• Output Current Capacity:
• Relay Outputs: 2 A
• Transistor Outputs: 0.5 A (standard), 0.1 A in PTO mode
• Mounting Flexibility: Compatible with DIN rail or panel mount installations
• Protection Class: IP20
• Operational Temperature Span: -10°C to +55°C
• Physical Dimensions (H x W x D): 90 mm x 150 mm x 95 mm
• Weight: Approximately 0.53 kg
• Compliance & Certifications: CE, UL, CSA, and various others

Applications

• Automated Industrial Processes: Delivers robust and reliable control for diverse manufacturing operations and complex machinery.
• Efficient Material Handling: Expertly manages conveyor systems, sorting mechanisms, and sophisticated automated storage and retrieval systems.
• Precision Packaging Solutions: Controls critical functions across filling, sealing, labeling, and other automated packaging equipment.
• HVAC System Management: Regulates heating, ventilation, and air conditioning units for optimal environmental control.
• Optimized Energy Management: Enables effective monitoring and strategic control of energy consumption within industrial facilities.

Why Choose This Model?

The Schneider Electric TM241CE24R stands out as a superior choice for modern industrial control applications due to its thoughtful design and powerful capabilities:

• Unmatched I/O Versatility: Boasts a highly adaptable I/O configuration, combining both relay and transistor outputs, to meet a wide spectrum of input and output demands.
• Superior Connectivity Options: Integrates multiple communication ports, including dedicated Ethernet, ensuring effortless integration into heterogeneous network environments.
• Exceptional Performance for Complex Tasks: Offers rapid processing speeds and sophisticated positioning functions, making it ideally suited for the most intricate automation challenges.
• Scalable and Future-Proof Architecture: Supports an impressive expansion capability with up to 7 local and 14 remote I/O modules, allowing your system to grow and adapt with evolving requirements.
• Intuitive Programming Environment: Fully compatible with the EcoStruxure Machine Expert software, providing an accessible and efficient platform for program development and deployment.

Order Now

Elevate your industrial automation capabilities with the Schneider Electric TM241CE24R Modicon M241 logic controller. Experience the difference that robust performance, flexible connectivity, and scalable design can make to your operational efficiency. Add to cart or contact us for expert advice and to secure your advanced control solution today.
