Pepperl+Fuchs UB800-18GM40-U-V1

Overview

The Pepperl+Fuchs UB800-18GM40-U-V1 (Part No. 205336) is an advanced, compact ultrasonic sensor engineered for precision non-contact distance measurement in demanding industrial environments. Housed within a durable M18 cylindrical design, this sensor delivers accurate readings up to an impressive 800 mm. Its versatile analog output, configurable for either 0–10 V or 4–20 mA, combined with a robust V1 (M12) connector, makes it an ideal solution for a multitude of applications. Whether you need to reliably monitor liquid levels, detect solid objects, or measure distances, this sensor performs exceptionally well, irrespective of the target material's color, transparency, or reflectivity. Its IP67 protection rating ensures resilience against dust and water ingress, while its wide operating voltage range guarantees stable performance across diverse industrial settings. Experience unparalleled reliability and precision with this top-tier ultrasonic sensing solution from Pepperl+Fuchs.

Key Features

• Extended Sensing Range: Accurately measures distances from 60 mm to 800 mm.
• Versatile Analog Output: Provides flexible 0–10 V or 4–20 mA analog output, adaptable to various control systems.
• Robust Housing: Features a sturdy M18 cylindrical, threaded housing for easy integration and long-lasting performance.
• Secure Electrical Connection: Equipped with a reliable V1 M12 4-pin connector for stable and secure wiring.
• Non-Contact Sensing: Offers precise measurements independent of material, color, or reflectivity of the target object.
• Superior Protection: Boasts an IP67 protection class, ensuring resistance to dust and water, ideal for harsh environments.
• Temperature Compensation: Integrated temperature compensation enhances measurement accuracy, even with fluctuating ambient temperatures.

Technical Specifications

• Model: UB800-18GM40-U-V1
• Part Number: 205336
• Measurement Range: 60–800 mm
• Output Signal: Analog (0–10 V or 4–20 mA, model dependent)
• Supply Voltage: 10–30 VDC
• Response Time: ≤ 300 ms
• Switching Frequency: ~5 Hz
• Connector Type: M12 (V1), 4-pin
• Operating Temperature: -25°C to +70°C
• Housing Material: Nickel-plated brass
• Mounting: Threaded M18
• Protection Rating: IP67

Applications

• Liquid and Solid Level Measurement: Precisely monitors levels in tanks, silos, and containers, ensuring optimal fill levels and preventing overflows or shortages.
• Object Detection: Reliably detects objects regardless of their surface characteristics, making it perfect for applications where optical sensors might fail due to color or transparency.
• Packaging & Conveying Systems: Provides accurate and consistent non-contact distance feedback for automation in high-speed production lines, optimizing material flow and preventing jams.
• Industrial Automation: An indispensable tool for measurement tasks where traditional optical sensors are unsuitable due to environmental factors such as dust, steam, or varying light conditions.

Why Choose This Model?

The Pepperl+Fuchs UB800-18GM40-U-V1 stands out as a superior choice for a multitude of industrial sensing needs. Its precise analog distance output offers granular control and monitoring, essential for critical applications. The sensor's highly versatile nature allows it to perform exceptionally across diverse environments, from manufacturing floors to processing plants. Its compact and rugged design, coupled with a V1 connector, not only ensures durability but also facilitates fast and straightforward wiring, minimizing installation time and effort. With its robust construction, reliable performance in challenging conditions, and a legacy of German engineering excellence from Pepperl+Fuchs, the UB800-18GM40-U-V1 is an investment in accuracy, efficiency, and longevity for your industrial automation systems.

Order Now

Enhance your industrial automation with the reliable and precise Pepperl+Fuchs UB800-18GM40-U-V1 ultrasonic sensor. This robust and versatile sensor is available for global delivery, ensuring that your operations worldwide can benefit from its advanced capabilities. Contact us today to place your order and experience the difference that quality engineering makes in your measurement and detection applications.
