Pepperl+Fuchs PMI120-F90-IU-V1

Overview

The Pepperl+Fuchs PMI120-F90-IU-V1 (Part No. 191136) is a state-of-the-art inductive positioning sensor designed for highly accurate, non-contact linear position detection. Engineered to provide continuous and reliable feedback across a generous 120 mm measuring range, this advanced unit is an indispensable component for a wide array of automation and motion control systems. Its robust design ensures unwavering performance even in the most challenging industrial environments, making it a superior choice for applications demanding precision and durability. With both current (4-20 mA) and voltage (0-10 V) analog outputs, it offers versatile integration into existing control architectures, providing seamless data transmission for optimal system functionality.

Key Features

• Extended Measuring Range: Precisely measures linear positions from 0 to 120 mm, catering to diverse application requirements.
• Versatile Analog IU Output: Features switchable current (4–20 mA) and voltage (0–10 V) outputs, providing flexible connectivity options for various control systems.
• High Resolution: Delivers exceptional accuracy with a resolution of 0.1 mm, capturing subtle changes in position.
• Superior Repeat Accuracy: Ensures consistent and reliable performance with an impressive repeat accuracy of ±0.15 mm, critical for repetitive processes.
• Wide Power Supply Range: Operates efficiently with a 15–30 VDC power supply, accommodating standard industrial power sources.
• Robust IP67 Protection: Fully sealed against dust and water ingress, guaranteeing reliable operation and extended lifespan in harsh conditions.
• Compact F90 Housing: Space-saving flat housing design (F90) allows for easy integration into confined spaces without compromising performance.
• Secure M12 5-pin Connector: Utilizes a standard M12 x 1 male, 5-pin connector for secure and straightforward installation.
• Broad Operating Temperature: Maintains optimal functionality across a wide temperature range from -25°C to +70°C, suitable for extreme industrial settings.
• Intuitive LED Indicators: Equipped with status and alignment LEDs for quick visual confirmation of operational status and simplified setup.

Technical Specifications

• Model Number: PMI120-F90-IU-V1
• Part Number: 191136
• Sensing Technology: Inductive linear measurement, offering non-contact and wear-free operation.
• Operating Voltage: 15–30 VDC
• Output Signal: Selectable 0–10 V or 4–20 mA analog output.
• Linearity Deviation: ≤ 1% of the measuring range, ensuring high fidelity of position data.
• Construction Materials: Durable plastic housing with a resilient LCP (Liquid Crystal Polymer) sensing face for longevity.
• Mounting: Designed for surface mounting with integrated alignment aid for simple and precise installation.
• Electrical Connection: M12 x 1 male, 5-pin connector.
• Weight: Approximately 250 g, contributing to ease of handling and installation.

Applications

• Packaging Machines: Provides continuous and accurate position tracking for various actuators, optimizing packaging efficiency and precision.
• Machine Tools: Enables precise part alignment and dependable travel detection, crucial for intricate machining operations.
• Robotics: Offers essential linear motion feedback for robotic end effectors, enhancing their accuracy and control in complex tasks.
• Advanced Automation Systems: Integrates seamlessly to provide vital position feedback in dynamic moving assemblies, improving overall system responsiveness.
• Material Handling Equipment: Facilitates accurate detection of moving load positions, contributing to safer and more efficient material flow.
• Hydraulic Cylinder Position Sensing: Ideal for non-contact measurement of cylinder rod position, offering a durable alternative to traditional solutions.
• Medical Equipment: Can be utilized in precision medical devices requiring accurate linear feedback.

Why Choose This Model?

The Pepperl+Fuchs PMI120-F90-IU-V1 stands out as an exceptional choice for demanding industrial applications due to its blend of advanced features and robust construction:

• ✅ Expansive 120 mm Measuring Range: Accommodates a broader spectrum of applications compared to sensors with smaller ranges.
• ✅ Dual Analog Output Flexibility: The choice between current and voltage output significantly simplifies integration into diverse control architectures, minimizing compatibility concerns.
• ✅ Space-Saving F90 Compact Housing: Its sleek, flat design allows for installation in tight spaces where traditional sensors might not fit.
• ✅ Unmatched Durability with IP67 Protection: Engineered to withstand harsh industrial environments, offering long-term reliability and reducing maintenance costs.
• ✅ Optimized for Continuous Linear Motion Monitoring: Provides the consistent and precise feedback essential for optimizing process control and automation.
• ✅ Trusted Pepperl+Fuchs Quality: Benefit from the renowned reliability and innovation associated with a leading global brand in industrial sensors.

Order Now

Elevate your automation and motion control systems with the unparalleled precision and reliability of the Pepperl+Fuchs PMI120-F90-IU-V1 inductive positioning sensor. Our global shipping ensures that this high-performance solution can reach you wherever your operations are located. Enhance your operational efficiency and accuracy today.
