Pepperl+Fuchs NRB2-8GM40-E2-C-V1

Overview

The Pepperl+Fuchs NRB2-8GM40-E2-C-V1, identified as Part No. 250524, is a high-performance M8 inductive proximity sensor meticulously engineered for precision and reliability in demanding industrial environments. This compact, flush-mountable sensor offers a dependable 2 mm sensing range, making it perfectly suited for detecting metallic objects with exceptional accuracy.

Equipped with a PNP normally open (NO) output, the NRB2-8GM40-E2-C-V1 seamlessly integrates into various control systems. Its robust design is further enhanced by an M8 connector, ensuring quick, secure, and reliable electrical connections. This sensor is an indispensable component for modern automation, providing non-contact detection solutions for an array of applications from machine tools to advanced robotics.

Key Features

• Manufacturer Part Number: 250524
• Sensor Type: Inductive proximity sensor
• Output Type: PNP, normally open (NO) for versatile system integration
• Sensing Distance: Precise 2 mm sensing for accurate object detection
• Mounting: Flush (shielded) in metal, allowing for seamless integration without protrusion
• Housing Size: Compact M8 x 1 threaded housing ideal for space-constrained applications
• Connection Type: Standard M8 connector, 3-pin (V1 type), for effortless installation
• LED Indicator: Integrated visual LED provides clear output status feedback, simplifying troubleshooting
• Protection Class: IP67-rated, ensuring superior resistance to dust and water ingress in harsh industrial settings
• Housing Material: Durable nickel-plated brass construction for long-lasting performance
• Temperature Range: Operates reliably across a wide temperature spectrum of –25 °C to +70 °C

Technical Specifications

• Model: NRB2-8GM40-E2-C-V1
• Part Number: 250524
• Operating Voltage: Wide operating voltage range of 10–30 V DC
• Current Output: Maximum 200 mA current output to drive various loads
• Switching Frequency: High switching frequency of up to 2 kHz for rapid response
• Short-Circuit Protection: Built-in short-circuit protection safeguards the sensor and system
• Polarity Reversal Protection: Integrated polarity reversal protection prevents damage from incorrect wiring
• Installation: Designed for flush mount in metal, ensuring a secure and stable installation
• Dimensions: Compact M8 diameter with a 40 mm length for versatile placement
• Connection: M8 male connector, 3-pin, for robust and industrial-grade connectivity
• Compliance: CE and cULus listed, affirming adherence to international safety and quality standards

Applications

• Factory Automation: Essential for accurate presence and position detection of metallic parts across automated lines.
• Robotics: Provides crucial feedback for precise actuator and gripper positioning, enhancing robotic arm functionality.
• Material Handling: Reliably detects objects on conveyor systems, optimizing flow and preventing bottlenecks.
• Packaging Machinery: Ideal for part detection in tight spaces within packaging equipment, ensuring efficient operation.
• OEM Equipment: Perfectly suited for embedded detection in small and custom-built machines, offering seamless integration.

Why Choose This Model?

The Pepperl+Fuchs NRB2-8GM40-E2-C-V1 stands out as an exceptional choice for a multitude of reasons. Its compact M8 form factor, combined with a rugged IP67-rated housing, guarantees superior durability and longevity even in the most challenging industrial environments. This sensor is engineered for reliable and fast detection of metallic objects, ensuring optimal performance and minimizing downtime in critical applications.

Installation and maintenance are streamlined thanks to its easy wiring capabilities with a standard M8 connector. This feature reduces installation time and simplifies troubleshooting processes. Furthermore, its small size and efficient design make it an ideal solution for high-density sensor installations, allowing for more comprehensive monitoring in limited spaces. When precision, durability, and ease of use are paramount, the NRB2-8GM40-E2-C-V1 delivers.

Order Now

The Pepperl+Fuchs NRB2-8GM40-E2-C-V1 (Part No. 250524) is currently in stock and available for immediate global shipment. Enhance your automation systems with this reliable, high-performance inductive proximity sensor. Place your order today to benefit from its advanced features and robust design.
