Pepperl+Fuchs 3RG6012-3AD00-PF

Overview

The Pepperl+Fuchs 3RG6012-3AD00-PF is a high-performance M30 ultrasonic proximity sensor engineered for exceptional precision in non-contact object detection. Designed for demanding industrial environments, this compact yet robust sensor accurately detects objects within a versatile 60 to 300 mm range. Its durable M30 nickel-plated brass housing ensures longevity and reliability, making it an ideal choice for a wide array of industrial automation applications where consistent and accurate sensing is paramount.

Key Features

• Precise Detection Range: Reliably senses objects from 60 mm up to 300 mm, offering flexibility for various application needs.
• PNP Normally Open (NO) Output: Provides a clear and decisive signal for seamless integration into control systems.
• Robust M30 Housing: Constructed from nickel-plated brass, guaranteeing superior durability and resistance to wear and tear in harsh industrial settings.
• Easy M12 Connectivity: Features a standard M12 connector for straightforward and rapid electrical integration, minimizing installation time.
• IP65 Environmental Protection: Fully protected against dust ingress and high-pressure water jets, ensuring reliable operation in challenging conditions.
• Efficient Switching Frequency: Operates at an impressive switching frequency of up to 8 Hz, suitable for fast-paced industrial processes.
• Wide Operating Temperature: Functions flawlessly across a broad temperature range from -25°C to +70°C, accommodating diverse operational climates.
• Optimized Operating Current: Supports a maximum operating current of 300 mA, ensuring compatibility with standard industrial power supplies.

Technical Specifications

• Model Number: 3RG6012-3AD00-PF
• Sensor Type: Ultrasonic Proximity Sensor
• Sensing Range: 60 to 300 mm
• Output Configuration: PNP, Normally Open (NO)
• Supply Voltage: 12 to 30 V DC
• Switching Frequency: Max 8 Hz
• Connection Type: M12 Connector
• Housing Material: Nickel-plated Brass
• Protection Class: IP65
• Operating Temperature: -25°C to +70°C
• Max Operating Current: 300 mA

Applications

• Industrial Automation: Essential for accurate object positioning, presence detection, and distance measurement on automated assembly lines and machinery.
• Material Handling Systems: Optimally utilized for monitoring the presence, fill levels, and precise placement of items on conveyor belts and in storage systems.
• Packaging and Bottling Machinery: Ensures the correct orientation and placement of products, reducing errors and improving line efficiency.
• Robotics: Provides critical non-contact detection capabilities for obstacle avoidance, gripper positioning, and safe operation in robotic cells.
• Level Control: Suitable for non-contact level measurement in small tanks or containers for various liquids and bulk materials.
• Door and Gate Control: Reliable detection for automatic doors, gates, and access control systems in industrial environments.

Why Choose This Model?

The Pepperl+Fuchs 3RG6012-3AD00-PF stands out as a superior choice for industrial sensing due to its blend of precision, durability, and ease of integration. Its accurate 60-300 mm detection range makes it versatile for numerous tasks, while the robust M30 nickel-plated brass housing ensures it can withstand the rigors of challenging industrial settings. The IP65 rating provides crucial protection against environmental elements, guaranteeing consistent performance. With its standard M12 connector, installation is remarkably straightforward, minimizing downtime and accelerating deployment. Choosing this model means investing in a reliable, high-performance ultrasonic sensor that enhances operational efficiency and sensor longevity.

Order Now

Elevate your industrial automation processes with the dependable performance of the Pepperl+Fuchs 3RG6012-3AD00-PF M30 Ultrasonic Sensor. This essential component is ready to enhance your systems with its precision and durability. Available for immediate shipping worldwide. Secure yours today and experience unparalleled sensing reliability.
