Omron NX-SID800

Overview

The Omron NX-SID800 is a high-performance 4-channel safety input module meticulously engineered to elevate the safety integrity of industrial automation systems utilizing Omron's NX-Series Safety Control Systems. This advanced unit, operating at a nominal 24V DC, is specifically designed to provide robust and precise monitoring of critical safety devices, ensuring stringent compliance with international safety standards. Its seamless integration capabilities and compact form factor make it an ideal choice for enhancing operational safety without compromising valuable control panel space.

This module is not just an input unit; it's a critical component in building a comprehensive and reliable safety infrastructure. By efficiently processing safety signals, the NX-SID800 helps to minimize risks, prevent accidents, and maintain continuous, safe operation in various industrial environments. Its intelligent design allows for straightforward implementation and dependable performance, making it a cornerstone for modern safety-conscious automation solutions.

Key Features

• Input Capacity: Provides 4 dedicated safety input points for comprehensive monitoring of multiple safety devices.
• Test Outputs: Features 2 integrated test output points, offering advanced diagnostics and verification of input signal integrity.
• Input Type: Utilizes sinking inputs (PNP), ensuring compatibility with a wide array of industrial safety sensors and devices.
• Rated Input Voltage: Optimized for 24V DC operation, with a wide operating range of 20.4 to 28.8 VDC for stable performance.
• Space-Saving Design: Boasts a remarkably slim profile, measuring 12 mm (W) × 104.5 mm (H) × 80.1 mm (D), perfect for optimizing cabinet space.
• Effortless Integration: Engineered for plug-and-play incorporation into existing or new Omron NX-Series Safety Control Systems.
• Global Safety Compliance: Fully compliant with leading international safety standards, including EN ISO 13849-1 (PLe/Safety Category 4) and IEC 61508 (SIL3).

Technical Specifications

• Model Number: NX-SID800
• Series: NX-Series
• Number of Safety Input Points: 4
• Number of Test Output Points: 2
• Internal I/O Common: PNP (sinking inputs)
• Rated Input Voltage: 24V DC (20.4 to 28.8 VDC)
• Input Current: 3.0 mA typical
• Input ON Voltage: 15 VDC min.
• Input OFF Voltage/OFF Current: 5 VDC max., 1 mA max.
• Test Output Type: Sourcing outputs (PNP)
• Test Output Load Current: 50 mA max.
• Test Output Residual Voltage: 1.2 V max.
• Test Output Leakage Current: 0.1 mA max.
• Dimensions: 12 mm (W) × 104.5 mm (H) × 80.1 mm (D)
• Weight: Approximately 70 g
• Mounting: DIN rail (IEC 60715 TH35-7.5/TH35-15)
• Operating Temperature: 0°C to +55°C
• Storage Temperature: -25°C to +65°C
• Operating Humidity: 10% to 95% (non-condensing)
• Certifications: CE, cULus, TUV, KC

Applications

• Industrial Automation: Critical for enhancing and maintaining safety monitoring in sophisticated automated manufacturing and assembly systems.
• Robotics: Provides dependable safety input processing, integral for the safe operation and human-robot collaboration in robotic work cells.
• Process Control: Essential for ensuring secure and compliant operation in complex process control environments where safety is paramount.
• Packaging Machinery: Monitors critical safety devices in high-speed packaging lines, effectively preventing accidents and ensuring operator protection.
• Materials Handling: Integrates into safety circuits for conveyors, automated guided vehicles (AGVs), and other material handling equipment.

Why Choose This Model?

The Omron NX-SID800 stands out as a superior choice for several compelling reasons:

• Uncompromising Safety Standards: Achieves and maintains compliance with the highest global safety standards, including PLe and SIL3, guaranteeing maximum reliability and peace of mind.
• Flexible and Seamless Integration: Engineered for effortless integration with existing or new Omron NX-Series Safety Control Systems, this module facilitates scalable and adaptable safety solutions for evolving industrial needs.
• Compact Efficiency: Its ultra-slim design not only conserves valuable panel space but also delivers robust and high-capacity safety input capabilities, optimizing your control systems without sacrificing performance.
• Reliable Performance in Demanding Environments: Built to withstand the rigors of industrial settings, the NX-SID800 ensures consistent, accurate, and dependable performance even in harsh operating conditions.
• Advanced Diagnostics: With integrated test outputs, the module provides comprehensive diagnostic capabilities, allowing for proactive maintenance and ensuring continuous system health.

Order Now

Elevate the safety and performance of your industrial automation systems today with the Omron NX-SID800 4-Channel Safety Input Module. Available for immediate shipping worldwide.
