Mitsubishi RX41C4

Overview

The Mitsubishi Electric RX41C4 is a high-precision, 4-channel analog output module meticulously engineered for seamless integration with the MELSEC R Series PLC. This robust module provides unparalleled flexibility with selectable voltage (0–10 V DC) or current (0–20 mA DC) outputs, all delivered with an exceptional 16-bit resolution. Designed to meet the stringent demands of modern industrial automation, the RX41C4 is ideal for applications requiring extremely accurate and reliable analog signal generation, enhancing the performance and efficiency of various process control systems.

Key Features

• Series Compatibility: Exclusively designed for the Mitsubishi MELSEC R Series PLC.
• Output Channels: Equipped with 4 independent analog output channels for versatile control.
• Flexible Output Types: User-selectable 0–10 V DC voltage or 0–20 mA DC current outputs.
• High Resolution: Boasts a 16-bit resolution for precise and granular signal control.
• Enhanced Isolation: Features reliable channel-to-system isolation, safeguarding the PLC from electrical noise.
• Diagnostic Indicators: Individual diagnostic LED per channel for quick status checks and troubleshooting.
• Mounting: Designed for convenient rack-mounted installation within the R Series system.

Technical Specifications

• Catalog Number: RX41C4
• Channels: 4 analog output channels
• Voltage Output Range: 0–10 V DC
• Current Output Range: 0–20 mA DC
• Resolution: 16-bit (approximately 0.15 mV or 0.3 µA steps)
• Load Requirements: ≥2 kΩ for voltage output, ≤600 Ω for current output
• Output Accuracy: ±0.1% of full scale
• Isolation Voltage: 1500 VAC (channel-to-system)
• Operating Temperature: 0 °C to 55 °C
• Storage Temperature: –25 °C to 75 °C
• Dimensions: Approximately 90 × 87 × 40 mm
• Weight: Approximately 0.35 kg
• Certifications: CE, UL, RoHS compliance for global standards.

Applications

• Proportional Control: Precise control of valves and actuators in various industrial settings.
• Process Automation: Critical for temperature, pressure, and flow control in complex industrial processes.
• HMI/SCADA Integration: Generates accurate analog signals for seamless integration with Human-Machine Interfaces and Supervisory Control and Data Acquisition systems.
• Closed-Loop Systems: Enhances the accuracy and stability of closed-loop industrial control systems.
• PLC Expansion: Serves as a compact and efficient module for expanding the capabilities of R Series PLCs.

Why Choose This Model?

• Unmatched Versatility: The RX41C4 offers dual output capability, allowing seamless switching between voltage and current outputs to suit diverse application requirements without needing separate modules.
• Superior Precision: With its 16-bit Digital-to-Analog Converter (DAC), this module ensures exceptionally precise signal control, which is crucial for sensitive industrial processes and maintaining optimal operational parameters.
• Robust Protection: Featuring true channel-to-system isolation, the RX41C4 effectively protects your valuable PLC from potential electrical noise and disturbances originating from the field, ensuring stable and reliable operation.
• Effortless Diagnostics: Equipped with integrated LED indicators for each channel, the module provides immediate visual feedback, significantly aiding in quick diagnostics and minimizing downtime.
• Seamless System Integration: Engineered to fit directly and perfectly into existing R Series racks, the RX41C4 guarantees hassle-free installation and immediate integration into your current Mitsubishi Electric automation infrastructure.

Order Now

Elevate your industrial control systems with the Mitsubishi Electric RX41C4 Analog Output Module. This high-performance module is readily available and ready to ship worldwide, ensuring you can enhance your automation capabilities no matter your global location. Explore the comprehensive Mitsubishi MELSEC iQ-R Series collection for additional compatible solutions within this advanced product family. Additionally, discover our extensive range of Mitsubishi MELSEC Programmable Controllers (PLC) to find scalable automation solutions tailored to your needs, from robust legacy MELSEC systems to next-generation PLCs designed for unparalleled performance, connectivity, and flexibility in modern industrial environments.
