Mitsubishi QY81P

Overview

The Mitsubishi QY81P is a high-performance 16-point digital output module meticulously engineered for seamless integration with the MELSEC-Q series PLCs. This versatile module provides exceptional flexibility with both sink and source output configurations, operating at a reliable 24V DC. Designed to meet the stringent demands of modern industrial automation, the QY81P excels at high-speed signal switching, making it the ideal solution for precisely controlling a diverse array of devices, including actuators, relays, solenoids, and indicator lights across a vast spectrum of automation systems. Its robust design and superior functionality ensure optimal performance and reliability in critical applications, enhancing overall system efficiency and control.

Key Features

• Series: MELSEC-Q
• Output Type: Transistor (sink/source selectable)
• Number of Outputs: 16 independent points
• Rated Voltage: 24V DC
• Output Current: 0.5A per point, with a maximum of 4A per common
• Switching Time: Ultra-fast response of ≤0.1ms
• Interface: Secure and reliable screw terminal block
• Isolation: Advanced photocoupler isolation for enhanced safety and noise immunity
• LED Indicators: Individual LED indicators for each output channel, providing clear status visualization
• Mounting: Designed for easy installation within a Q-series base unit
• Protection: Integrated overcurrent and short-circuit protection safeguards the module and connected devices

Technical Specifications

• Model Number: QY81P
• Voltage: 24V DC (capable of both sink and source configurations)
• Total Output Points: 16
• Max Current per Point: 0.5A
• Max Current per Common: 4A
• Response Time: ≤0.1ms
• Insulation Type: Photocoupler isolation
• Mounting Type: Rack mount (specifically for Q series base units)
• Operating Temperature: 0°C to 55°C
• Dimensions: Approximately 98 x 27.4 x 90 mm
• Weight: ≈ 0.2 kg
• Certifications: CE, UL, cUL, RoHS compliant

Applications

The Mitsubishi QY81P is a highly adaptable digital output module, suitable for a wide range of industrial applications:

• Precise control of indicator lights and signal towers for visual status feedback.
• Efficient driving of relays, solenoids, and small actuators in automated processes.
• Integration into conveyor and packaging systems for responsive material handling.
• Seamless operation within machine tools and general industrial automation setups.
• Reliable output signaling for critical alarms and monitoring devices, ensuring operational safety.

Why Choose This Model?

• Flexible Output Mode: Offers unparalleled adaptability with support for both sink and source wiring configurations, catering to diverse system requirements.
• Rapid Switching: Boasts an impressive response time of under 0.1ms, enabling real-time control and immediate reaction to process changes.
• Compact & Modular Design: Its optimized form factor allows for effortless integration into MELSEC-Q base units, maximizing space efficiency within control cabinets.
• Safe & Reliable Operation: Equipped with robust built-in short-circuit and overcurrent protection, safeguarding both the module and critical connected equipment from potential damage.
• Industry Standard Excellence: Represents proven reliability and performance within global automation systems, backed by the trusted Mitsubishi Electric brand.

Order Now

The Mitsubishi QY81P 16-point digital output module is readily available worldwide to enhance your automation infrastructure. Explore our extensive collection of Mitsubishi MELSEC-Q Series for additional compatible options and expand your system capabilities. For comprehensive automation solutions, delve into our full range of Mitsubishi MELSEC Programmable Controllers (PLC), offering everything from legacy systems to cutting-edge PLCs engineered for superior performance, advanced connectivity, and unparalleled flexibility.
