Mitsubishi QY80

Overview

Unleash precise and reliable control within your automation systems with the Mitsubishi QY80 Digital Output Module. Engineered for seamless integration with MELSEC-Q Series PLCs, this high-performance module provides 32 channels of 24V DC sink-type outputs, enabling rapid and efficient switching for a diverse array of industrial applications. From actuating relays and solenoids to managing indicator lights and motor controls, the QY80 delivers the responsiveness and stability demanded by modern manufacturing and process automation environments. Its compact design optimizes valuable panel space, while integrated LED indicators offer instant, per-point diagnostic feedback, streamlining commissioning and troubleshooting.

Key Features

• High-Density Outputs: 32 individual digital output channels for comprehensive control.
• Reliable Output Type: 24V DC sink (transistor) outputs ensure efficient and stable operation.
• Optimized Current Handling: Rated for 0.5A per point and 2A per common, accommodating various loads.
• Rapid Response Time: Designed for fast switching, crucial for time-sensitive control processes.
• Instant Diagnostics: Integrated LED indicators provide immediate status monitoring for each output point.
• Space-Saving Design: Compact form factor ideal for high-density control cabinet installations.
• Robust Isolation: Photocoupler isolation safeguards your PLC from load-side disturbances.

Technical Specifications

• Model: QY80
• Series: MELSEC-Q
• Rated Load Voltage: 24V DC (operating range 20.4–26.4V DC)
• Rated Load Current: 0.5A per point, 2A per common
• Number of Common Terminals: 4 points per common
• Insulation Method: Photocoupler isolation for enhanced protection
• Mounting Compatibility: Designed for installation in a Q-series base unit slot
• Operating Temperature: 0°C to 55°C (32°F to 131°F)
• Weight: Approximately 0.2 kg (0.44 lbs)
• Certifications: CE, UL, cUL compliant, ensuring global applicability and safety standards.

Applications

The versatility and high-performance characteristics of the Mitsubishi QY80 make it an indispensable component across a broad spectrum of industrial applications, including:

• Precise control of relays and solenoids in machinery.
• Efficient switching for indicator lights and alarm systems.
• Implementing motor start/stop logic in automated lines.
• Integral to advanced process automation systems.
• Core component in factory machine control and robotics.
• Building management systems (BMS) for HVAC and lighting control.

Why Choose This Model?

The Mitsubishi QY80 stands out as a superior choice for demanding control tasks due to its:

• Exceptional Channel Density: Consolidate 32 outputs into a single module, optimizing panel real estate and simplifying wiring.
• Unwavering Reliability & Speed: Benefit from fast and dependable switching, critical for maintaining the integrity and timing of automation sequences.
• Streamlined Troubleshooting: Integrated LED indicators on each point drastically reduce diagnostic time, minimizing downtime and maximizing operational efficiency.
• Flawless MELSEC-Q Integration: Engineered specifically for the MELSEC-Q Series, guaranteeing seamless compatibility and peak performance within your existing or new PLC architecture.
• Mitsubishi Electric Quality: Rely on the renowned quality and engineering excellence of Mitsubishi Electric, ensuring a long-lasting and robust solution for your industrial needs.

Order Now

Enhance your automation capabilities today with the Mitsubishi QY80 Digital Output Module. This essential component is currently in stock and available for immediate shipment to power your next project.

Looking for more options within the MELSEC-Q family? Return to our Mitsubishi MELSEC-Q Series collection to explore a wider range of modules and solutions.

For a comprehensive overview of scalable control solutions, delve into our full selection of Mitsubishi MELSEC Programmable Controllers (PLC). Discover innovative systems ranging from proven legacy platforms to cutting-edge next-generation PLCs, all designed for unparalleled performance, connectivity, and adaptability.
