Mitsubishi QY40P

Overview

The Mitsubishi QY40P is a high-performance 32-point digital output module meticulously engineered for seamless integration with MELSEC-Q series Programmable Logic Controllers (PLCs). This robust module provides reliable and precise control for a multitude of industrial applications, featuring 24V DC source-type transistor outputs. Its compact design, rapid response time, and user-friendly screw terminal wiring ensure efficient and dependable operation. Built for longevity in demanding industrial environments, the QY40P incorporates photocoupler isolation for enhanced safety and is perfectly suited for driving critical components such as indicator lights, relays, and various actuators.

Key Features

• Series: MELSEC-Q
• Output Type: Transistor (source type, PNP)
• Rated Voltage: 24V DC
• Output Points: 32
• Output Current: 0.5A per point, 4A per common
• Wiring Method: Screw terminal block
• Isolation: Photocoupler per channel
• Response Time: ≤ 0.1 ms
• Mounting: Designed for installation in a Q-series base unit
• Protection: Integrated overcurrent and short-circuit protection
• Status Indicators: Individual LED status indicators per output channel

Technical Specifications

• Catalog Number: QY40P
• Voltage Range: 15–30V DC
• Output Type: Source (PNP) transistor
• Points per Module: 32
• Maximum Current per Point: 0.5A
• Maximum Current per Common: 4A
• Response Time: ≤ 0.1 ms
• Leakage Current (OFF): ≤ 0.1 mA
• Voltage Drop (ON): ≤ 0.5V
• Insulation Type: Photocoupler
• Mounting Method: Rack mount (MELSEC-Q base unit)
• Operating Temperature: 0°C to 55°C
• Dimensions: Approx. 98 x 27.4 x 90 mm
• Weight: ≈ 0.2 kg
• Certifications: CE, UL, RoHS

Applications

The versatility and robust performance of the Mitsubishi QY40P make it an ideal solution for a broad spectrum of industrial automation applications, including:

• Precise control of solenoids and actuators in manufacturing processes
• Reliable illumination for signal towers and indicator lamps
• Efficient operation of conveyor systems in material handling
• Integration into various material handling equipment for automated tasks
• Seamless control within machine automation panels for enhanced functionality

Why Choose This Model?

The Mitsubishi QY40P stands out as a superior choice for enhancing your MELSEC-Q PLC systems due to several key advantages:

• High-Density Outputs: Benefit from 32 output points packed into a remarkably compact module, maximizing space efficiency in your control cabinets.
• Fast Switching Capability: With a rapid response time of ≤ 0.1 ms, the QY40P is perfectly suited for real-time automation systems demanding quick and precise control.
• Uncompromised Safety & Reliability: Integrated photocoupler isolation per channel, coupled with overcurrent and short-circuit protection, ensures safe and dependable operation in critical industrial environments.
• Effortless Wiring: The inclusion of screw terminals significantly simplifies both installation and ongoing maintenance, reducing downtime and operational costs.
• Full Compatibility: Enjoy seamless integration with existing and new MELSEC-Q platforms, ensuring a smooth upgrade path and consistent performance across your automation infrastructure.

Order Now

Elevate the capabilities of your industrial automation systems with the Mitsubishi QY40P digital output module. This essential component is readily available and ships worldwide to meet your global operational needs. For additional options within this highly regarded product family, we invite you to explore our comprehensive Mitsubishi MELSEC-Q Series collection. Furthermore, discover our extensive range of Mitsubishi MELSEC Programmable Controllers (PLC) to find scalable automation solutions tailored for every requirement, from established legacy MELSEC systems to the most advanced next-generation PLCs engineered for unparalleled performance, connectivity, and flexibility.
