Mitsubishi QX10

Overview

The Mitsubishi QX10 is an essential 8-point digital input module meticulously engineered for seamless integration within the robust Mitsubishi Q Series PLC platform. This versatile module efficiently processes 24V DC sink or source signals, providing a highly reliable and space-saving solution for incorporating discrete input signals into diverse industrial automation environments. Designed for precision and durability, the QX10 streamlines the connection of sensors, switches, and other field devices, ensuring accurate data acquisition and enhanced operational control. Its compact design not only conserves valuable cabinet space but also contributes to a cleaner, more organized control system.

Key Features

• Series: Part of the high-performance Mitsubishi Q Series, ensuring compatibility and advanced functionality.
• Number of Inputs: Equipped with 8 distinct input channels for comprehensive signal collection.
• Input Type: Offers flexible sink/source selectable input, accommodating various wiring configurations.
• Rated Input Voltage: Operates efficiently at 24V DC, a standard in industrial applications.
• Response Time: Rapid response time of 1.5 ms max for swift signal processing.
• Input Indicator: Features an intuitive LED indicator per channel for quick visual status checks.
• Isolation: Each input benefits from photocoupler isolation, enhancing system protection and signal integrity.
• Terminal Type: Utilizes a secure screw-type removable terminal block for effortless wiring and maintenance.
• Mounting: Versatile mounting options including DIN rail or direct base unit integration.

Technical Specifications

• Catalog Number: QX10 - The definitive identifier for this module.
• Input Points: 8 - Facilitating multiple device connections.
• Rated Input Voltage: 24V DC ±10% - Guarantees stable operation within specified voltage ranges.
• Input Current: Approximately 7 mA - Optimized for efficient power consumption.
• Input Method: Sink/source - Provides adaptability to different control system architectures.
• Insulation Method: Photocoupler - Ensures electrical isolation between input and internal circuitry.
• Response Time: 1.5 ms or less - Critical for applications requiring fast and precise signal detection.
• Ambient Temperature: 0°C to 55°C - Designed for reliable performance in typical industrial conditions.
• Protection Rating: IP20 (installed) - Offers protection against solid objects, ensuring longevity.
• Weight: Approximately 0.2 kg - Lightweight design for easy handling and installation.
• Certifications: CE, UL, RoHS - Complies with international safety and environmental standards.

Applications

The Mitsubishi QX10 digital input module is an indispensable component across a wide spectrum of industrial applications:

• Machine Input Signal Capture: Accurately reads signals from various machine components and sensors.
• Discrete Input from Sensors and Switches: Ideal for processing ON/OFF signals from proximity sensors, limit switches, and pushbuttons.
• Packaging Machinery Automation: Enhances the efficiency and control of packaging lines by monitoring various inputs.
• Conveyor Systems and Part Tracking: Facilitates precise monitoring of product movement and positioning on conveyor belts.
• General-Purpose I/O for Q Series Systems: Serves as a fundamental interface for integrating diverse field devices into Q Series PLC architectures.

Why Choose This Model?

The Mitsubishi QX10 stands out as a superior choice for your industrial automation needs due to several compelling advantages:

• Compact Size: Its remarkably small footprint is engineered to maximize space utilization within your control cabinets, allowing for more streamlined and efficient designs.
• Reliable Input Processing: With a rapid response time and robust design, the QX10 is perfectly suited for handling high-speed signals, minimizing latency and ensuring critical data is captured accurately.
• Flexible Wiring: The sink/source compatibility provides unparalleled flexibility, allowing for seamless integration into existing systems regardless of their wiring methodology, simplifying installation and reducing potential configuration complexities.
• Easy Integration: As a dedicated component of the Mitsubishi Q Series platform, the QX10 guarantees effortless installation and immediate compatibility, reducing setup time and accelerating deployment.
• Diagnostic LEDs: Equipped with individual LED indicators per channel, the module offers immediate and clear visual feedback on the status of each input, significantly aiding in troubleshooting, diagnostics, and system maintenance.

Order Now

Elevate your industrial automation capabilities with the Mitsubishi QX10 digital input module. This advanced module is readily available and poised for worldwide shipment, ensuring you can enhance your systems regardless of your location. To explore further options and expand your automation solutions, we invite you to return to our comprehensive Mitsubishi MELSEC-Q Series collection. Additionally, discover our full spectrum of Mitsubishi MELSEC Programmable Controllers (PLC) to uncover scalable and high-performance automation solutions, ranging from legacy MELSEC systems to the latest generation of PLCs designed for unparalleled connectivity and flexibility.
