Mitsubishi MR‑CCN1

Overview

The Mitsubishi MR-CCN1 Servo Network Converter is a cutting-edge solution designed to seamlessly integrate Mitsubishi Electric's high-performance SSCNET servo systems with CC-Link industrial networks. This compact yet powerful device acts as a crucial gateway, allowing direct communication between MR-J2 and MR-J3 series servo amplifiers and CC-Link-based automation architectures. Engineered for efficiency and ease of installation, the MR-CCN1 streamlines motion control configurations, making it an indispensable component for modern factories aiming for optimized operational fluidity and reduced system complexity. Its robust design ensures reliable performance in demanding industrial environments, providing a dependable backbone for your automation needs.

Key Features

• Function: Bidirectional protocol conversion between SSCNET and CC-Link for effortless system interoperability.
• Compatible Series: Specifically engineered for perfect compatibility with Mitsubishi Electric MR-J2 and MR-J3 servo amplifiers.
• Mounting: Offers flexible installation options, supporting both standard DIN-rail and panel mounting for diverse setups.
• Network Ports: Equipped with a dedicated SSCNET port and CC-Link connection terminals for comprehensive connectivity.
• LED Indicators: Features clear LED indicators for power status, network activity, and fault conditions, enabling quick diagnostics.
• Configuration: User-friendly configuration via DIP switches or intuitive software settings for tailored operational parameters.
• Compact Design: Boasts a space-saving architecture, ideal for integration into control cabinets where space is at a premium.

Technical Specifications

• Model Number: MR-CCN1
• Protocol Conversion: SSCNET to CC-Link
• SSCNET Speed: Up to 10 Mbps
• CC-Link Speed: Up to 10 Mbps
• Servo Axis Support: Up to 4 axes per unit
• Power Supply: 24 V DC (supplied via control power)
• Ambient Temperature: 0 °C to 55 °C
• Protection Rating: IP20 (when installed)
• Mounting Dimensions: Approximately 90 mm × 60 mm × 100 mm
• Weight: Approximately 0.3 kg
• Certifications: CE, UL

Applications

• Enabling seamless integration of MR-J2 and MR-J3 servo systems into existing CC-Link PLC network infrastructures.
• Facilitating the precise control of multi-axis motion systems managed under CC-Link platforms.
• Optimizing retrofitting projects, allowing older SSCNET systems to be efficiently upgraded to modern CC-Link environments.
• Ideal for Original Equipment Manufacturer (OEM) machines that demand flexible and robust network integration capabilities.
• Enhancing automation processes in critical industries such as semiconductor manufacturing, packaging, and advanced robotics.

Why Choose This Model?

The Mitsubishi MR-CCN1 stands out as an exceptional choice for industries requiring reliable network conversion. Its primary strength lies in its unparalleled protocol bridging capability, ensuring that your SSCNET servo systems can effortlessly communicate and operate within a CC-Link network without extensive overhauls. With support for up to 4 servo amplifiers per unit, it offers a scalable solution for various motion control requirements. The compact gateway design of the MR-CCN1 is a significant advantage, minimizing the footprint required within control cabinets, thus saving valuable space. Furthermore, the integrated LED indicators provide instant visual feedback on power, network status, and potential faults, greatly simplifying troubleshooting and maintenance. Coupled with its straightforward installation process, featuring DIN-rail compatibility and standard connectors, the MR-CCN1 offers a robust, efficient, and user-friendly solution for complex industrial automation needs.

Order Now

The Mitsubishi MR-CCN1 servo network converter is readily available to enhance your industrial automation systems. This essential component is available for immediate purchase and benefits from our worldwide shipping service, ensuring that this pivotal technology can reach your operations, wherever they may be. Elevate your system's connectivity and performance today by integrating the MR-CCN1 into your setup.
