Mitsubishi FX5-16EYR-ES

Overview

Elevate the control capabilities of your Mitsubishi FX5U Series PLC systems with the Mitsubishi FX5-16EYR-ES, a robust 16-point relay output extension module. Engineered for seamless integration, this module significantly expands your output capacity, offering precise and reliable control over a wide array of industrial applications. Featuring durable SPST-NO mechanical relay contacts, the FX5-16EYR-ES is perfectly suited for efficiently switching both AC and DC loads, providing exceptional flexibility in your automation designs. Powered by a standard 24V DC supply, this extension module is not just an add-on; it's a fundamental enhancement designed to provide durable, flexible, and responsive output control that meets the rigorous demands of modern industrial environments.

Key Features

• Extensive Output Capacity: Equipped with 16 independent relay outputs to manage multiple devices simultaneously.
• Versatile Output Type: Utilizes SPST-NO (Single Pole, Single Throw – Normally Open) mechanical relays, ideal for various load types.
• High Rated Load: Each output point supports up to 2A (resistive), with an impressive 8A per common, ensuring robust power handling.
• Standard Power Supply: Operates efficiently on a 24V DC power supply, compatible with most industrial setups.
• Instant Status Feedback: Individual LED indicators for each output provide immediate visual confirmation of operational status.
• Flexible Mounting Options: Designed for convenient DIN rail or panel mounting, adapting to your specific enclosure requirements.
• Plug-and-Play Integration: Engineered for direct, hassle-free connection and compatibility with Mitsubishi FX5U series PLCs, minimizing setup time.

Technical Specifications

• Model: FX5-16EYR-ES
• Series: FX5U
• Insulation Resistance: >5 MΩ (measured with a 500V DC megger), ensuring high electrical safety.
• Dielectric Strength: Capable of withstanding 1000V AC for 1 minute, providing enhanced protection against voltage spikes.
• Response Time: Approximately 10 ms, for quick and efficient switching operations.
• Ambient Temperature: Operational in a wide range from 0°C to 55°C, suitable for diverse industrial settings.
• Dimensions: Approximately 90 x 90 x 85 mm (H x W x D), designed for efficient space utilization.
• Weight: Approximately 0.35 kg (0.77 lbs), lightweight for easy handling and installation.
• Certifications: Compliant with CE, UL, and RoHS standards, affirming global usability and environmental responsibility.

Applications

The Mitsubishi FX5-16EYR-ES module is an indispensable component across various sectors requiring reliable and flexible output control:

• Industrial Machinery Control: Provides precise activation and deactivation of machinery components, enhancing automation workflows.
• Motor and Solenoid Switching: Ideal for controlling industrial motors, solenoids, and actuators with high reliability.
• Light and Indicator Actuation: Perfect for managing signal lights, alarms, and other visual indicators in control panels and factory floors.
• HVAC and Building Automation: Enables integration into building management systems for controlling heating, ventilation, air conditioning, and access points.
• Factory Process Automation: Essential for managing various stages of manufacturing processes, from start/stop commands to sequential operations.

Why Choose This Model?

The FX5-16EYR-ES stands out as a superior choice for enhancing your automation infrastructure due to several compelling advantages:

• Flexible Output Expansion: Seamlessly integrates with your existing FX5U PLC, dramatically expanding its relay control capabilities without complex reconfigurations.
• Reliable Operation: Built with robust mechanical relays, this module guarantees consistent and dependable switching performance, minimizing downtime and maximizing productivity.
• Easy Installation & Compatibility: Engineered for direct compatibility with the FX5U series, ensuring a straightforward, plug-and-play installation process that saves time and resources.
• Global Standards Compliance: Fully certified with CE, UL, and RoHS, this module is not only safe and environmentally friendly but also recognized for its quality and performance worldwide, assuring peace of mind for international applications.
• Enhanced System Resilience: By offering a dedicated expansion for output, it helps distribute the control load, thereby increasing the overall resilience and longevity of your PLC system.

Order Now

Ready to upgrade your control system? The Mitsubishi FX5-16EYR-ES 16-Point Relay Output Extension Module is currently in stock and available for immediate shipment worldwide. Don't miss the opportunity to enhance your industrial automation with this high-performance, reliable component.

For more options and to explore related products, we invite you to return to our comprehensive Mitsubishi FX5 Series PLC collection. Discover our full range of Mitsubishi MELSEC Programmable Controllers (PLC) to find scalable automation solutions tailored for both legacy systems and next-generation PLCs, all designed for unparalleled performance, connectivity, and flexibility.
