Mitsubishi FX3U-4DA-ADP

Overview

The Mitsubishi FX3U-4DA-ADP is a high-performance 4-channel analog output expansion module engineered specifically for seamless integration with Mitsubishi Electric FX3U and FX3UC Series PLCs. This robust adapter provides exceptional precision and flexibility, offering both voltage (0–10V, 1–5V) and current (4–20 mA) output capabilities with an impressive 12-bit resolution. Designed for intricate industrial automation demanding fine-tuned control, the FX3U-4DA-ADP empowers engineers to precisely regulate a wide array of devices, from actuators and motors to sophisticated process control systems. Its compact design ensures efficient use of valuable panel space, making it an ideal choice for streamlining and enhancing your control architecture.

Key Features

• 4 Analog Output Channels: Provides ample connectivity for multiple analog control points.
• Versatile Output Types: Supports both voltage (0–10V, 1–5V) and current (4–20 mA) outputs to suit diverse application requirements.
• High 12-bit Resolution: Delivers superior accuracy with 1/4096 steps for precise analog signal generation.
• ADP (Adapter) Mount: Designed for convenient side-mounting directly onto FX3U/FX3UC Series PLCs, ensuring a secure and space-saving connection.
• Compact and Efficient Design: Optimizes control cabinet space, reducing the overall footprint of your automation system.
• Intuitive Status Indicators: Integrated LEDs provide immediate visual feedback for diagnostics and real-time output monitoring, simplifying troubleshooting and maintenance.

Technical Specifications

• Model: FX3U-4DA-ADP
• Series Compatibility: FX3U / FX3UC
• Output Range: Individually configurable per channel for either voltage or current.
• Conversion Speed: Approximately 1 ms per channel, ensuring rapid and responsive signal updates.
• Operating Temperature: 0°C to 55°C, suitable for a wide range of industrial environments.
• Mounting: Specifically designed for side-mounting on the PLC main unit, providing a streamlined installation.
• Weight: Approximately 0.15 kg (0.33 lbs), contributing to a lightweight and manageable control system.
• Certifications: Conforms to CE, UL, and RoHS standards, guaranteeing quality, safety, and environmental compliance.

Applications

The Mitsubishi FX3U-4DA-ADP is a highly adaptable module, perfect for a multitude of industrial scenarios requiring accurate analog output control:

• Analog Actuator Control: Precisely position and operate various actuators in automated machinery.
• Speed Regulation for VFDs: Provide variable frequency drives (VFDs) with accurate speed setpoints for motor control.
• Temperature and Pressure Regulation: Maintain optimal environmental conditions in process control applications.
• Signal Output to Analog Instruments: Interface seamlessly with a wide range of analog gauges, meters, and recording devices.
• Precise Analog Interfacing in Compact PLC Systems: Enhance the capabilities of space-constrained control systems without compromising performance.

Why Choose This Model?

The Mitsubishi Electric FX3U-4DA-ADP stands out as an exceptional choice for expanding your PLC’s analog capabilities due to several compelling advantages:

• Seamless Expandability: Effortlessly adds essential analog output functionality without increasing the physical footprint of your existing PLC system.
• Unmatched Versatility: The ability to select between voltage and current output modes for each channel offers unparalleled adaptability to diverse industrial requirements.
• Proven Mitsubishi Reliability: Benefit from Mitsubishi Electric’s renowned engineering excellence, ensuring industrial-grade performance, durability, and a long operational lifespan.
• Optimized for Compact Systems: Its innovative side-mount design makes it the perfect solution for applications where cabinet space is at a premium, allowing for denser and more efficient control layouts.
• Enhanced Control Precision: The 12-bit resolution guarantees highly accurate and sensitive control over your analog processes, leading to improved operational efficiency and product quality.

Order Now

The Mitsubishi FX3U-4DA-ADP 4-Channel Analog Output Expansion Block is currently in stock and available for immediate shipment, ensuring prompt integration into your automation projects. Elevate your control system's capabilities with this high-precision module.

For further enhancements to your control network, explore the extensive range of Mitsubishi FX3 Series PLCs, including high-performance compact controllers such as FX3U, FX3UC, FX3G, and FX3S models. Additionally, discover the complete selection of Mitsubishi MELSEC Programmable Controllers (PLC) to find scalable automation solutions tailored for machine control, motion, networking, and a broad spectrum of industrial applications.
