Mitsubishi FX2N-32ER-ES/UL

Overview

Elevate the capabilities of your automation systems with the Mitsubishi FX2N-32ER-ES/UL, a premium relay output expansion module meticulously engineered for seamless integration with FX2N PLC main units. This indispensable module significantly extends your control horizon by providing an impressive 32 additional I/O points, precisely balanced with 16 inputs and 16 robust relay outputs. Designed to operate flawlessly within automation environments powered by 100–240 V AC, the FX2N-32ER-ES/UL empowers your systems with enhanced versatility and control precision, solidifying its position as a cornerstone for reliable industrial operations.

Key Features

• Expansive I/O Capacity: Delivers a total of 32 I/O points, comprising 16 digital inputs and 16 high-performance relay outputs, ensuring comprehensive control over diverse applications.
• Wide Power Compatibility: Operates efficiently with a 100–240 V AC power supply, making it suitable for a broad range of industrial power infrastructures.
• Precision Relay Outputs: Features reliable relay outputs, ideal for switching higher current loads often encountered in industrial machinery and control panels.
• Effortless Integration: Engineered for seamless and straightforward integration with existing Mitsubishi FX2N main units, minimizing setup time and maximizing operational efficiency.
• Convenient Wiring: Equipped with built-in terminal blocks, facilitating quick, secure, and hassle-free wiring for both inputs and outputs.
• Flexible Mounting Options: Offers versatile mounting choices, including standard DIN-rail or direct panel mounting, adapting to various enclosure designs and installation preferences.
• Robust Construction: Housed in a compact yet rugged enclosure, ensuring durability and consistent performance in demanding industrial environments.
• Globally Certified: UL and CE certified, guaranteeing compliance with stringent international safety and quality standards, enabling worldwide deployment.

Technical Specifications

• Catalog Number: FX2N-32ER-ES/UL
• Inputs: 16 digital points (configurable for sink/source wiring)
• Outputs: 16 relay points (2 A maximum current per point)
• Input Voltage: 100–240 V AC, 50/60 Hz
• Response Time: 10 ms (typical)
• Mounting: DIN rail or direct panel mount
• Protection Class: IP10 (open type)
• Power Consumption: Approximately 30 VA
• Dimensions (W×H×D): 150 × 90 × 86 mm
• Certifications: CE, UL, cUL

Applications

• PLC I/O Expansion: Indispensable for expanding the input/output capabilities of OEM equipment and complex machinery where an increased number of control points is required.
• Conveyor and Motor Control: Provides robust control for various conveyor systems, motor starters, and advanced motion control applications, ensuring smooth and reliable operation.
• Industrial Process Monitoring: Perfect for monitoring and controlling critical parameters within industrial processes, including temperature, pressure, and level control systems.
• HVAC and Building Automation: An excellent choice for enhancing control in Heating, Ventilation, Air Conditioning (HVAC) systems and generalized building automation, optimizing energy efficiency and environmental control.
• Control Panels: Optimally suited for integration into small-to-mid-size control panels, offering a compact yet powerful solution for diverse industrial automation needs.

Why Choose This Model?

The Mitsubishi FX2N-32ER-ES/UL stands out as a superior choice for several compelling reasons. Its ability to provide seamless and reliable I/O expansion for your critical FX2N controllers ensures that your systems can grow and adapt to evolving operational demands. With flexible mounting and wiring options, installation and maintenance are streamlined, reducing downtime and operational complexities. The module's easy installation and configuration further enhance its user-friendliness, allowing for rapid deployment and quick integration into existing setups. Moreover, its durable construction and comprehensive industrial certifications guarantee long-term stability and consistent performance even in the most challenging industrial environments. By choosing the FX2N-32ER-ES/UL, you are not just selecting an expansion module; you are investing in a component backed by Mitsubishi Electric's renowned legacy of automation excellence, ensuring reliability, precision, and longevity for your automation infrastructure.

Order Now

Unlock the full potential of your Mitsubishi FX2N PLC system today. The Mitsubishi FX2N-32ER-ES/UL I/O expansion module is readily available in stock and can be shipped worldwide, ensuring prompt delivery to your location. For additional options and to explore related products within this family, please return to the Mitsubishi FX2N / FX2NC Series PLC. To discover an even wider array of advanced automation solutions engineered for unparalleled reliability, flexibility, and scalability, we invite you to explore the complete range of Mitsubishi MELSEC Programmable Controllers (PLC).
