Mitsubishi FR-A7NC

Overview

The Mitsubishi FR-A7NC is an advanced CC-Link communication option card meticulously engineered for seamless integration with the acclaimed FR-A700 series variable frequency drives (VFDs). This crucial component empowers your industrial automation systems by facilitating robust and reliable communication across CC-Link networks. With the FR-A7NC, you can unlock unparalleled remote control capabilities, comprehensive diagnostics, and precise monitoring of your drives directly from a master controller or Programmable Logic Controller (PLC). Its innovative design ensures efficient data exchange, contributing to optimized operational efficiency and system management.

Key Features

• Seamless Compatibility: Specifically designed for the Mitsubishi FR-A700 series VFDs, ensuring perfect fit and function.
• CC-Link Network Integration: Fully compliant with CC-Link (Control & Communication Link) network standards for widespread applicability.
• Versatile Connection: Offers flexible connectivity options with both RJ-45 and screw terminal interfaces.
• Flexible Mounting: Can be conveniently mounted on a DIN rail or directly onto the drive, adapting to various industrial setups.
• Intuitive Address Setting: Features an easy-to-use rotary switch for node address configuration (supporting 1–64 nodes).
• Comprehensive Diagnostics: Provides real-time network error detection, detailed node status reports, and continuous communication monitoring for enhanced reliability.
• Efficient Data Transmission: Supports both cyclic and transient data transmission, catering to diverse application requirements.
• Rapid Response Time: Achieves a swift response time of ≤ 1.5 ms within a standard CC-Link network, ensuring timely control.
• Integrated Power Supply: Draws power directly from the inverter, simplifying wiring and installation.

Technical Specifications

• Catalog Number: FR-A7NC
• Communication Protocol: CC-Link Ver. 1.10
• Transmission Speed: Up to 10 Mbps, supporting high-speed data exchange.
• Maximum Stations: Capable of managing up to 64 stations on a single network.
• Mounting Style: Designed for plug-in installation (into inverter) or DIN rail mounting.
• Ambient Temperature: Operates reliably within a temperature range of 0°C to 55°C.
• Protection Class: IP00, suitable for protected environments.
• Dimensions: Approximately 90 x 80 x 40 mm, compact for easy integration.
• Weight: Approximately 0.15 kg, lightweight and robust.
• Certifications: CE, UL, RoHS compliant, ensuring adherence to international standards.

Applications

• Automated Production Lines: Facilitates precise remote drive control in fully automated manufacturing and assembly lines.
• Multi-Axis Control Systems: Enables synchronized multi-axis motor control across CC-Link networks for complex movements.
• Factory and Process Automation: Essential for integrating VFDs into comprehensive factory and process automation architectures.
• Distributed Control Systems: Ideal for implementing distributed systems utilizing FR-A700 VFDs, enhancing scalability and flexibility.
• Network-Based Energy Management: Supports advanced energy management strategies through network-wide monitoring and control of VFDs.

Why Choose This Model?

The Mitsubishi FR-A7NC stands out as the optimal choice for enhancing your FR-A700 series inverters due to its unwavering reliability and advanced features. It provides seamless integration, allowing your FR-A700 drives to connect effortlessly with any CC-Link network. Experience unparalleled control and peace of mind with remote diagnostics, enabling you to monitor performance and detect potential issues from a centralized location, minimizing downtime. With its fast response capabilities, supporting high-speed data transmission, the FR-A7NC ensures your critical operations are always responsive and efficient. Its easy setup, featuring intuitive rotary switch addressing and straightforward wiring, significantly reduces installation time and complexity. Furthermore, its proven compatibility, being specifically designed for Mitsubishi drives, guarantees optimal performance and longevity, making it a wise investment for your industrial automation needs.

Order Now

Elevate the capabilities of your industrial systems with the Mitsubishi FR-A7NC CC-Link communication option card. This essential component ensures robust communication and advanced control for your FR-A700 series variable frequency drives. The Mitsubishi FR-A7NC is readily available and we are pleased to offer worldwide shipping, ensuring that your vital components arrive wherever your operations demand. Secure your FR-A7NC today and take a significant step towards a more interconnected and efficient automation environment.
