Mitsubishi CM900DU-24NF

Overview

Engineered for the most demanding industrial applications, the Mitsubishi Electric CM900DU-24NF stands as a high-performance IGBT module designed to deliver unparalleled power and efficiency. This robust dual-transistor IGBT module boasts a formidable 900 A current rating and a 1200 V blocking voltage, making it an ideal choice for heavy-duty operations where reliability and optimal power conversion are paramount. Leveraging cutting-edge trench-gate technology and integrated fast-recovery diodes, the CM900DU-24NF ensures rapid and efficient switching, significantly reducing power losses and optimizing thermal management within your systems. Its insulated base provides superior thermal transfer, contributing to the module's longevity and stable performance even under extreme operating conditions. Trust Mitsubishi Electric for industrial-grade solutions.

Key Features

• Dual IGBT Half-Bridge Configuration: Optimized for high-power switching applications.
• Exceptional Current Handling: A continuous collector current of 900 A supports intensive power demands.
• High Voltage Capacity: Boasts a 1200 V collector-emitter voltage for robust operation.
• Advanced Trench-Gate IGBT Structure: Ensures superior switching characteristics and energy efficiency.
• Integrated Fast-Recovery Diodes: Minimizes switching losses and enhances overall performance.
• Insulated Baseplate: Facilitates efficient thermal dissipation, extending component lifespan.
• Rugged Chassis Mount Package: Designed for durability and reliable operation in harsh industrial environments.
• Optimized for High-Current Industrial Use: Tailored to meet the rigorous demands of heavy industrial machinery.

Technical Specifications

• Part Number: CM900DU-24NF
• Configuration: Dual IGBT
• Collector Current (Continuous): 900 A
• Collector-Emitter Voltage: 1200 V
• VCE(sat): Approximately 2.0–2.2 V at rated current
• Gate-Emitter Voltage: ±20 V
• Switching Speed: Fast
• Thermal Resistance (Junction-Case): Approximately 0.025 °C/W
• Mounting Type: Chassis mount (insulated)
• Operating Temperature: –40 °C to +150 °C
• Package Type: High-power IGBT module
• Weight: Approximately 800–900 g

Applications

The Mitsubishi Electric CM900DU-24NF IGBT module is engineered to excel in a diverse range of high-power industrial applications, providing stability and efficiency where it matters most:

• High-Capacity Inverters and Drives: Essential for precise motor control in large-scale industrial machinery.
• Industrial Automation and Robotics: Powers critical systems requiring reliable and efficient power conversion.
• Traction and Railway Systems: Ensures robust performance in demanding transportation infrastructure.
• Wind and Solar Power Converters: Optimizes energy conversion for sustainable power generation.
• Large-Scale UPS and Energy Systems: Guarantees uninterrupted power supply and efficient energy management.

Why Choose This Model?

Selecting the Mitsubishi Electric CM900DU-24NF IGBT module is a strategic decision for any application demanding peak performance and unwavering reliability. This module distinguishes itself with its massive 900 A current rating and 1200 V blocking voltage, providing a robust foundation for even the most power-intensive operations. Its exceptional efficiency and superior thermal performance are a testament to Mitsubishi Electric's commitment to advanced engineering, ensuring your systems operate smoothly and with minimal energy waste. With Mitsubishi Electric's renowned quality and commitment to long-term reliability, you are investing in a component that will stand the test of time, reducing maintenance and replacement costs. Designed for the most demanding power applications, the CM900DU-24NF offers simplified mounting thanks to its insulated baseplate, streamlining installation and enhancing operational safety. Choose the CM900DU-24NF for a powerful, efficient, and reliable solution.

Order Now

The Mitsubishi Electric CM900DU-24NF IGBT module is readily available and ready for worldwide shipment. This high-performance component is an integral part of our comprehensive collection of Mitsubishi IGBT Modules, specifically engineered to meet the rigorous demands of high-efficiency power conversion and ensure reliable operation across a vast spectrum of industrial automation tasks. We encourage you to browse our complete range of Mitsubishi IGBT Modules to discover other cutting-edge solutions. Furthermore, expand your search within our main category of Power Electronics Components, where you will find an extensive selection of essential semiconductor solutions, including diodes, thyristors, GTOs, MOSFETs, and many more, all designed to empower your most critical projects.
