Mitsubishi A1S68DAV

Overview

The Mitsubishi Electric A1S68DAV is a robust and high-precision analog input module engineered to seamlessly integrate with MELSEC AnS and Q Series PLC systems. This versatile module offers 8 voltage input channels, each providing exceptional 16-bit resolution, making it an indispensable component for applications demanding accurate voltage measurement and reliable process control. Designed for the rigorous environments of industrial automation, the A1S68DAV ensures precise analog signal acquisition, thereby enhancing the performance and stability of your control systems. Its advanced features and compatibility make it a cornerstone for efficient data monitoring and process optimization across various industries.

Key Features

• Series Compatibility: Fully compatible with Mitsubishi Electric MELSEC AnS and Q Series PLC systems, ensuring broad integration capabilities.
• High Channel Density: Features 8 independent analog input channels, optimizing space and reducing hardware requirements.
• Input Type: Dedicated for voltage inputs, specifically supporting a 0–10 V DC range, suitable for a wide array of sensors.
• Superior Resolution: Boasts a 16-bit resolution, providing highly accurate and granular data acquisition for critical applications.
• Rapid Sampling Speed: Achieves a typical sampling speed of 10 ms per channel, ensuring timely data updates and responsive control.
• Isolation: Incorporates channel-to-system photocoupler isolation, safeguarding your PLC from field signal noise and potential damage.
• Diagnostic Indicators: Equipped with individual status LEDs for each input channel, facilitating quick diagnostics and troubleshooting.
• Mounting: Designed as a rack-mounted module for secure and organized installation within industrial control panels.

Technical Specifications

• Catalog Number: A1S68DAV
• Number of Channels: 8 analog voltage inputs
• Voltage Range: 0–10 V DC
• Resolution: 16-bit
• Conversion Time: Approximately 10 ms per channel
• Input Accuracy: ±0.1% full scale
• Isolation Voltage: 1500 VAC
• Operating Temperature: 0 °C to 55 °C
• Storage Temperature: –25 °C to 75 °C
• Dimensions: Approximately 90 × 87 × 40 mm
• Weight: Approximately 0.35 kg
• Certifications: CE, UL

Applications

The Mitsubishi Electric A1S68DAV analog input module is an ideal solution for a diverse range of industrial applications, including but not limited to:

• Accurate signal acquisition from 0–10 V sensors, such as those used for pressure, level, flow, and temperature measurements.
• Implementation within critical process control loops in various manufacturing and automation systems.
• Enhancing data logging and monitoring systems by providing reliable and precise analog input data.
• Integration into building automation and HVAC control systems for environmental monitoring and management.
• Expanding analog I/O capabilities for existing PLC systems, offering increased flexibility and scalability.

Why Choose This Model?

Opting for the Mitsubishi Electric A1S68DAV means investing in precision, reliability, and seamless integration for your industrial automation needs. Its high 16-bit resolution ensures unparalleled accuracy in voltage measurements, critical for maintaining tight process control and data fidelity. The robust isolation separates field signals from PLC logic, protecting your valuable control system from electrical interference and ensuring operational stability. With 8 inputs packed into a compact form factor, the A1S68DAV maximizes channel density without compromising on performance or increasing panel space requirements. Furthermore, individual LEDs for each channel provide clear and instant diagnostic feedback, greatly simplifying troubleshooting and reducing downtime. Its proven compatibility with both MELSEC AnS and Q Series PLCs guarantees versatile integration into existing and new automation architectures, making the A1S68DAV a smart and dependable choice for demanding industrial environments.

Order Now

Elevate your industrial automation system with the Mitsubishi Electric A1S68DAV analog input module. This high-performance module is available and ready to ship worldwide, ensuring you can quickly implement its advanced capabilities into your operations. Beyond this module, we invite you to explore our comprehensive Mitsubishi MELSEC-A Series PLC collection for additional options within this esteemed product family. For a complete overview of scalable and cutting-edge automation solutions, delve into our entire range of Mitsubishi MELSEC Programmable Controllers (PLC), featuring systems designed for high performance, superior connectivity, and unparalleled flexibility, catering to both legacy installations and next-generation industrial demands.
