Mitsubishi AC10TB

Overview

The Mitsubishi Electric AC10TB is a high-performance 10-point AC input terminal board engineered to seamlessly integrate with your MELSEC-A, MELSEC-F, or MELSEC-Q series Programmable Logic Controllers (PLCs). This robust unit minimizes wiring complexity by providing a streamlined, organized interface for AC signal inputs. Designed for industrial control cabinets, it guarantees stable, interference-free distribution of signals, which is crucial for maintaining the integrity and reliability of your automation processes. Its intuitive design also facilitates straightforward maintenance, reducing downtime and operational costs in demanding industrial environments.

Key Features

• 10 AC Input Points: Efficiently manages multiple AC signals, centralizing connectivity for enhanced system organization.
• 24 V DC Input Voltage: Compatible with both sink and source configurations, offering versatile integration options for various sensor and control devices.
• LED Indicators: Provides instant visual feedback on input status, significantly simplifying troubleshooting and real-time monitoring.
• Secure Screw-Terminal Design: Ensures reliable and robust electrical connections, resisting vibrations and environmental stresses typical in industrial settings.
• Compact Form Factor: Optimally designed for space-constrained panel-mounted racks, maximizing cabinet real estate.
• Plug-in Modular Design: Facilitates rapid and tool-free replacement, minimizing maintenance time and optimizing system uptime.
• Broad Compatibility: Fully compatible with MELSEC-A, MELSEC-F, and MELSEC-Q series base units, offering extensive flexibility across different PLC generations.
• Certified Reliability: UL, CE, and RoHS compliant, guaranteeing adherence to stringent safety and environmental standards.

Technical Specifications

• Catalog Number: AC10TB
• Input Points: 10 distinct digital AC inputs
• Input Voltage Range: 20–30 V DC, ensuring compatibility with standard industrial voltage levels.
• Current per Point: Typically 5 mA, indicating low power consumption for each input.
• Terminal Type: Screw terminals, providing secure and durable wiring connections.
• Mounting: Versatile mounting options via DIN rail or panel-mounted terminal board rack.
• Response Time: <5 ms, ensuring rapid detection and processing of input signals.
• Power Consumption: Features a low current draw, contributing to energy efficiency within the control system.
• Operating Temperature: 0 °C to +55 °C, suitable for a wide range of industrial operating conditions.
• Certifications: CE, UL, cUL, and RoHS, affirming global compliance and product quality.

Applications

The Mitsubishi Electric AC10TB terminal board is an indispensable component in a variety of industrial automation scenarios:

• Discrete Signal Wiring: Essential for organizing digital inputs from various field devices to PLC systems.
• Status Feedback Systems: Reliably collects and distributes status signals from sensors, limit switches, and gate positions.
• Automation Control Panels: Crucial for maintaining clean and organized signal routing within complex control panel layouts.
• OEM Machinery Integration: Ideal for original equipment manufacturers requiring compact, reliable input boards for their custom automation solutions.
• Cross-Industry Use: Widely adopted in packaging, material handling, assembly systems, and other manufacturing processes where precise signal input is critical.

Why Choose This Model?

Opting for the Mitsubishi Electric AC10TB significantly enhances the efficiency and reliability of your industrial automation systems. Its 10-point design profoundly simplifies PLC input wiring, transforming complex cable spaghetti into a clean, manageable interface. The integrated LED status indicators are a game-changer for troubleshooting, allowing maintenance personnel to quickly identify and address issues, thereby minimizing diagnostic time. Furthermore, its broad compatibility across the MELSEC-A, MELSEC-F, and MELSEC-Q PLC series provides unparalleled flexibility for system design and upgrades. With its compact and modular plug-in design, the AC10TB ensures quick installation and replacement, making it an ideal choice for creating tidy, highly organized, and efficient industrial panel layouts. Invest in the AC10TB for a robust, user-friendly, and dependable solution for your AC input signal management needs.

Order Now

The Mitsubishi Electric AC10TB 10-point AC Input Terminal Board is readily available and can be shipped worldwide to meet your project deadlines. For a comprehensive selection of high-quality cable options specifically designed for factory automation and motion control applications, we invite you to explore our offerings at Mitsubishi Cable Industries. Additionally, discover our full catalog of Mitsubishi Industrial Automation Products, featuring an extensive range of servo motors, drives, Human-Machine Interfaces (HMIs), connectivity solutions, and other advanced automation components to complete your control system.
