Lenze E82ZAFSC

Overview

The Lenze E82ZAFSC is a robust and essential braking resistor module meticulously engineered for seamless integration with the acclaimed Lenze 8200 series drives. This critical component plays a pivotal role in systems requiring precise and rapid deceleration, facilitating the efficient dissipation of kinetic energy generated during braking. By converting excess energy into heat, the E82ZAFSC safeguards your drive system from potentially damaging overvoltage conditions, ensuring smooth, controlled stops and prolonging the operational lifespan of your machinery.

Key Features

• Dedicated Application: Specifically designed for the effective dissipation of energy during dynamic braking cycles.
• Optimized Compatibility: Guarantees perfect integration and performance with all Lenze 8200 series frequency inverters.
• Significant Power Rating: Boasts a substantial 5.5 kW power rating, suitable for demanding applications.
• Advanced Resistor Technology: Utilizes high-efficiency ceramic resistors for superior heat transfer and sustained performance.
• Flexible Mounting: Designed for convenient panel-mounted installation, simplifying system integration.
• Robust Enclosure: Features an IP20 enclosure, offering protection against solid foreign objects and ensuring reliability in industrial environments.

Technical Specifications

• Rated Voltage: Capable of handling 480 V AC, aligning with common industrial power standards.
• Maximum Current: Supports a maximum current of 15 A, indicating its capacity for rigorous energy handling.
• Operating Ambient Temperature: Functions reliably across a broad range from -10°C to +45°C, suitable for diverse operational climates.
• Compact Dimensions (H x W x D): Approximately 210 mm x 130 mm x 150 mm, allowing for efficient use of cabinet space.
• Moderate Weight: Weighs approximately 3.5 kg, facilitating easy handling and installation.
• Industry Certifications: Complies with CE, UL, and RoHS standards, affirming its quality, safety, and environmental responsibility.

Applications

The Lenze E82ZAFSC braking resistor is an indispensable component in a wide array of industrial applications where reliable dynamic braking is paramount:

• High-Inertia Load Systems: Essential for machinery with significant rotational inertia, ensuring quick and safe stopping.
• Elevators and Hoists: Provides crucial energy dissipation for controlled ascent and descent, enhancing safety and performance.
• Fast-Stopping Conveyors: Enables rapid and precise stopping of conveyor belts, critical for production efficiency and safety.
• Industrial Machinery Requiring Dynamic Braking: Broadly applicable across various industrial sectors where controlled deceleration is a key operational requirement.

Why Choose This Model?

Opting for the Lenze E82ZAFSC braking resistor means investing in superior performance, reliability, and protection for your industrial applications. This model stands out due to its:

• Exceptional Energy Dissipation: Engineered for highly efficient energy conversion during braking, preventing heat buildup and potential system damage.
• Critical System Protection: Actively safeguards valuable drive systems from overvoltage conditions, extending their lifespan and reducing downtime.
• Durable Construction: Features high-efficiency ceramic resistors renowned for their robustness and ability to withstand continuous, demanding operation.
• Effortless Integration: Designed for seamless and straightforward integration with all Lenze 8200 series drives, minimizing installation complexity.

Order Now

Elevate the performance and reliability of your Lenze 8200 series drive systems with the Lenze E82ZAFSC braking resistor. Ensure smooth, controlled, and safe braking performance even in the most demanding high-inertia applications. Experience enhanced operational efficiency and extend the life of your equipment.
