Beckhoff EL2819
$802.99
Sale price
$802.99
Regular price
Overview
The Beckhoff EL2819 is a state-of-the-art 8-channel digital input EtherCAT Terminal meticulously engineered for the high-speed detection of 24 V DC signals. This advanced unit guarantees swift and dependable acquisition of vital signals originating from an array of sensors, switches, and other binary devices. It serves as a cornerstone for robust industrial automation and precision machine control systems, ensuring that critical data is captured with unparalleled accuracy and minimal latency. Designed for seamless integration within demanding industrial environments, the EL2819 empowers engineers to build more responsive and sophisticated control architectures.Key Features
- 8 Digital Input Channels: Provides ample connectivity for multiple sensors and binary devices.
- High-Speed Detection: Achieves rapid signal acquisition with a typical response time of just 0.2 µs, crucial for time-sensitive applications.
- 24 V DC Input Voltage: Standardized voltage input for broad compatibility with industrial sensors and control systems.
- Short-Circuit and Overload Protection: Integrated protective mechanisms safeguard the terminal and connected components from electrical faults, ensuring long-term reliability.
- Diagnostic LEDs for Status Monitoring: Clear visual indicators provide immediate feedback on channel status, simplifying fault identification and maintenance.
- Compact DIN-Rail Terminal Design: Optimizes space utilization within control cabinets, offering flexible and efficient installation.
- EtherCAT Integration: Seamlessly integrates into high-performance Beckhoff EtherCAT I/O networks for real-time control and data exchange.
- Robust Industrial Construction: Built to withstand challenging operational conditions, ensuring consistent performance.
Technical Specifications
- Beckhoff Code: EL2819
- Type: Digital Input Terminal
- Channels: 8
- Input Voltage: 24 V DC
- Nominal Current per Channel: typ. 4 mA
- Current Consumption (from bus): typ. 60 mA
- Response Time: 0.2 µs typ.
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: -25 °C to +85 °C
- Relative Humidity: 95 % (no condensation)
- Vibration Resistance: Conforms to EN 60068-2-6
- Shock Resistance: Conforms to EN 60068-2-27
- Mounting: 35 mm DIN rail
- Certifications: CE, UL, CUL, GL
- Isolation: 500 Vrms (channel/bus)
Applications
The Beckhoff EL2819 is an indispensable component for a wide range of industrial applications demanding precision and speed in digital signal processing. Its capabilities make it perfectly suited for:- High-Speed Digital Signal Acquisition: Essential in processes where rapid changes in state must be captured accurately.
- Monitoring Sensors, Switches, and Machine Inputs: Provides real-time status updates from push buttons, limit switches, proximity sensors, and more.
- Process and Industrial Automation: Enhances the responsiveness and reliability of automated production lines and control systems.
- Integration with Beckhoff EtherCAT I/O Networks: Maximizes the benefits of the ultra-fast EtherCAT communication protocol for distributed I/O.
- Machine Control and Safety Applications: Crucial for implementing interlocking mechanisms, emergency stops, and other safety-critical functions where fast response is paramount.
- Packaging and Printing Machinery: Ensures precise synchronization and control of various machine operations.
- Robotics: Facilitates rapid communication between robot controllers and external sensors for dynamic movements and interactions.
