B&R X20AT4222

Overview

The B&R X20AT4222 is a cutting-edge 2-channel analog input module, an integral component of the renowned X20 Series. Engineered for direct thermocouple connections, this module delivers unparalleled accuracy and stability for temperature measurement in the most demanding industrial automation environments. Its sophisticated design accommodates a wide array of thermocouple types, boasting integrated cold junction compensation for superior measurement integrity. This robust module ensures reliable and precise temperature monitoring, critically vital for maintaining optimal process control and operational efficiency across various industries.

Key Features

• Number of Inputs: 2 highly sensitive analog channels.
• Input Type: Comprehensive support for a broad spectrum of thermocouples, including Types J, K, L, N, R, S, T, B, E.
• Resolution: Exceptional 16-bit resolution ensures highly accurate and granular temperature readings.
• Cold Junction Compensation: Integrated per channel, providing automatic and precise compensation for ambient temperature fluctuations.
• Diagnostics: Advanced diagnostic capabilities detect open circuits and wire breaks, minimizing downtime and enhancing system reliability.
• Mounting: Designed for convenient DIN rail mounting, seamlessly integrating with the X20 standard backplane.
• LED Indicators: Clear status and error signaling via intuitive LED indicators for quick visual diagnostics.

Technical Specifications

• Model Number: X20AT4222
• Series: X20
• Input Channels: 2
• Sensor Types Supported: J, K, L, N, R, S, T, B, E
• Resolution: 16-bit ADC
• Cold Junction Compensation: Yes, integrated
• Conversion Time: Typically < 100 ms per channel
• Isolation: Channel-to-bus and channel-to-channel isolation for enhanced protection and signal integrity.
• Power Supply: Reliably powered via the X20 backplane.
• Mounting Method: DIN rail with X20 terminal blocks.
• Operating Temperature: A wide range of -25°C to +60°C, suitable for diverse industrial settings.
• Dimensions (H x W x D): Approximately 99 mm x 12.5 mm x 76 mm, a compact footprint for space-constrained applications.
• Protection Rating: IP20, providing protection against solid objects.
• Certifications: CE, UL, RoHS compliant, ensuring adherence to global quality and safety standards.

Applications

• Industrial Temperature Monitoring: Provides accurate thermal data essential for precise process control in manufacturing, energy, and more.
• Ovens & Furnaces: Ensures reliable thermocouple input for high-temperature equipment, critical for industries like metallurgy and ceramics.
• Machine Automation: Facilitates robust thermal supervision within embedded systems, safeguarding machinery and optimizing performance.
• Food & Pharma: Enables sensitive and critical temperature tracking in environments where hygiene and precise control are paramount, such as food processing and pharmaceutical manufacturing.

Why Choose This Model?

The B&R X20AT4222 stands out as the premier choice for demanding industrial applications requiring precise temperature measurement. Its High Accuracy, bolstered by a 16-bit resolution, guarantees meticulous temperature monitoring, crucial for maintaining product quality and process integrity. The module's Versatile Thermocouple Support means it can adapt to a multitude of industrial scenarios and sensor types, offering unparalleled flexibility. Its Compact Design allows for seamless integration into even the most crowded control cabinets, maximizing space efficiency without compromising performance. Furthermore, with Robust Diagnostics, including wire break and error detection, the X20AT4222 significantly enhances system reliability and minimizes costly downtime, providing peace of mind for continuous operations. Choosing the X20AT4222 means investing in reliability, precision, and operational excellence for your industrial automation needs.

Order Now

Elevate your industrial automation capabilities with the B&R X20AT4222. This essential 2-channel thermocouple analog input module is currently in stock and available for immediate worldwide delivery. Experience the difference that B&R's commitment to quality and innovation can make in your operations. Transform your temperature monitoring systems with a module designed for precision and reliability.
