Schneider Electric ATV320U04N4B

Overview

Introducing the Schneider Electric ATV320U04N4B, a cutting-edge variable speed drive from the acclaimed Altivar Machine ATV320 series. Engineered to deliver exceptional performance in a remarkably compact footprint, this VSD is your ultimate solution for precisely controlling 3-phase synchronous and asynchronous motors. Boasting a robust 0.37 kW (0.5 HP) power rating and adaptable 380–500V input voltage, the ATV320U04N4B is meticulously crafted for seamless integration into space-constrained control panels and a diverse range of OEM machinery. Experience the advantage of integrated EMC filtering for a clean, stable operation, ensuring your applications run optimally with enhanced integrity.

Key Features

• Optimized Power Output: Delivers 0.37 kW (0.5 HP) for efficient energy use.
• Versatile Voltage Handling: Operates reliably across a 380–500V ±10%, 3-phase input.
• Broad Motor Compatibility: Supports both asynchronous and permanent magnet motor types for flexibility.
• Integrated Electromagnetic Compatibility: Features a built-in Class C3 EMC filter, significantly reducing electrical interference.
• Advanced Motor Control Methods:
  • Voltage/Frequency (V/f) for standard applications.
  • Sensorless Flux Vector Control (SFVC) for enhanced speed and torque regulation without an encoder.
  • Flux Vector Control (FVC) with encoder feedback for the most precise and dynamic motor control.
• Adjustable Output Frequency: Offers a wide range from 0.1 to 599 Hz to suit various operational demands.
• Flexible Switching Frequency: Default 4 kHz, adjustable between 2–16 kHz for fine-tuned motor acoustics and efficiency.
• Integrated Safety Functionality: Equipped with a Safe Torque Off (STO) function, meeting essential machine safety requirements.
• Seamless Communication Protocols:
  • Embedded Modbus RTU for straightforward integration.
  • Embedded CANopen for robust industrial networking.
  • Extendable with optional expansion modules for Ethernet/IP, Profibus, and more.
• Adaptable I/O Configuration: Multiple digital and analog I/O options for comprehensive system integration.

Technical Specifications

The Schneider Electric ATV320U04N4B is engineered to the highest standards, offering dependable performance across diverse industrial settings. Its robust design and precise specifications ensure consistent operation and longevity.

• Model Identifier: ATV320U04N4B
• Product Series: Altivar Machine ATV320
• Motor Power Rating: 0.37 kW (0.5 HP)
• Nominal Output Current: 1.3 A, suitable for continuous operation.
• Maximum Transient Current: Capable of 2.0 A for up to 60 seconds, handling sudden load demands effectively.
• Ingress Protection: IP20 rated, providing protection against solid objects larger than 12mm.
• Installation Flexibility: Designed for convenient wall or panel mounting configurations.
• Operational Temperature Range: -10°C to +50°C without the need for derating, ensuring reliability in various climates.
• Altitude Performance: Functions optimally up to 1000 meters without derating.
• Physical Dimensions (W x H x D): 72 mm x 143 mm x 158 mm, engineered for compact installations.
• Product Weight: Approximately 1.2 kg, facilitating easy handling and installation.

Applications

The versatility and compact design of the Schneider Electric ATV320U04N4B make it an indispensable asset across numerous industries and applications:

• Conveyor Systems & Small-Scale Machinery: Provides fundamental yet precise speed and torque control for efficient material movement and automated processes.
• HVAC Infrastructure: Ideal for optimizing the performance of fans and small pumps, contributing to energy savings and improved air quality management.
• Packaging Automation: Serves as a vital component for Original Equipment Manufacturers (OEMs) seeking compact and reliable motor control solutions for intricate packaging machinery.
• General Material Handling: Excellently suited for light-duty automation tasks, enhancing productivity and operational smoothness in various logistical scenarios.
• Textile Production: Offers fine control for various textile machinery, improving product consistency and reducing waste.
• Laboratory Equipment: Guarantees stable and precise operation for sensitive lab instruments where motor control accuracy is paramount.

Why Choose This Model?

Opting for the Schneider Electric ATV320U04N4B means investing in a solution that brings together efficiency, reliability, and advanced control within a single, streamlined unit. This model stands out for several compelling reasons:

• Unbeatable Compactness: Its remarkably small footprint makes it an ideal choice for confined spaces and high-density panel layouts, maximizing valuable real estate.
• Integrated Excellence in Control: Benefit from trusted, reliable motor control combined with built-in safety features like STO and integrated EMC filtering, ensuring both performance and compliance.
• Effortless Connectivity: With embedded Modbus and CANopen, plus options for further network expansion, integration into existing or new control systems is straightforward and efficient.
• Optimized for Performance: Specifically designed to deliver efficient and consistent performance for low-power industrial applications, reducing energy consumption and operational costs.
• Schneider Electric Reliability: Leverage the trusted quality and support synonymous with Schneider Electric, a global leader in energy management and automation.

Order Now

Ready to enhance your machinery's performance with the Schneider Electric ATV320U04N4B Variable Speed Drive? Secure your unit today and experience the difference of precision engineering. Benefit from our fast shipping services and worldwide delivery options to get your product when and where you need it. Discover the full range of Schneider Electric Altivar 320 VFDs or explore other Schneider Electric Variable Frequency Drives to find the perfect match for your industrial requirements.
