Allen-Bradley 509-DOD

Overview

The Allen-Bradley 509-DOD is a robust and reliable NEMA-rated full voltage non-reversing starter, meticulously engineered for the efficient and safe direct-on-line starting of AC induction motors. This Size 3 starter is a cornerstone for industrial applications requiring consistent motor control and protection. Designed with precision, it integrates a 115-120V 60Hz coil for standard power compatibility and an indispensable eutectic alloy overload relay to safeguard your valuable motors from potentially damaging overcurrent conditions. As an open-type device, the 509-DOD is perfectly suited for integration within a protective enclosure, offering flexibility in installation while ensuring optimal performance and longevity in various demanding environments. This starter is a testament to Allen-Bradley's commitment to quality and durability, providing a dependable solution for your motor control needs.

Key Features

• NEMA Compliant Design: Adheres to stringent NEMA standards, ensuring proven performance, interchangeability, and robust construction.
• Seamless Direct-on-Line Operation: Facilitates full voltage non-reversing motor starting, providing straightforward and effective single-direction control.
• Optimized Size 3 Capacity: Engineered for specific motor applications, offering the ideal balance of physical size and operational capacity.
• Standardized 115-120V AC Coil: Equipped with a reliable 115-120V AC, 60Hz coil, ensuring compatibility with common industrial control systems.
• Advanced Eutectic Alloy Overload Protection: Features a high-performance eutectic alloy overload relay for precise and dependable thermal protection against motor overloads.
• Versatile Open-Type Configuration: Designed as an open-type starter, allowing for flexible mounting within a suitable enclosure for enhanced environmental and personnel protection.

Technical Specifications

The Allen-Bradley 509-DOD is a meticulously crafted magnetic starter designed for superior motor control.

• Product Type: Full Voltage Non-Reversing Starter / Magnetic Starter
• Catalog Number: 509-DOD
• NEMA Size: 3
• Coil Voltage: 115-120V AC, 60Hz
• Overload Relay Type: Eutectic Alloy
• Enclosure Type: Open Type (Requires separate enclosure for protection)

Applications

The Allen-Bradley 509-DOD non-reversing starter is a versatile component essential for a wide array of industrial applications, providing reliable motor control in:

• Direct-on-line starting and stopping of critical AC induction motors.
• Controlling and protecting pumps in water treatment, HVAC, and manufacturing.
• Managing fans in ventilation systems, industrial cooling, and air handling units.
• Operating conveyor systems for material handling in warehousing and logistics.
• Automating various machinery and processes requiring single-direction motor operation.

Why Choose This Model?

The Allen-Bradley 509-DOD stands out as a premier choice for professionals seeking robust and dependable motor control solutions:

• Unmatched Reliability: Built with Allen-Bradley's renowned quality, ensuring long-term performance and minimal downtime.
• Superior Motor Protection: The integrated eutectic alloy overload relay provides critical thermal protection, extending motor lifespan and preventing costly failures.
• NEMA Standard Compliance: Guarantees adherence to industry-recognized standards for performance and dimensional consistency.
• Cost-Effective Solution: Offers an excellent balance of advanced features and competitive pricing, providing significant value for your investment.
• Ease of Integration: Its open-type design allows for seamless integration into existing or new control panels, offering installation flexibility.
• Trusted Brand Legacy: Benefit from the peace of mind that comes with choosing a product from Allen-Bradley, a global leader in industrial automation.

Order Now

Elevate your industrial control systems with the Allen-Bradley 509-DOD NEMA Size 3 Full Voltage Non-Reversing Starter. Experience reliable performance, superior motor protection, and the trusted quality of Allen-Bradley products. Add to your cart today and ensure the efficient operation of your machinery. For additional options, explore our complete range of Allen-Bradley 509 Contactors or browse our extensive selection of Allen-Bradley Industrial Automation Products.
