Allen-Bradley 1797-IBN16

Overview

Unlock superior control and data acquisition in your industrial automation systems with the Allen-Bradley 1797-IBN16 POINT I/O 16-Point Digital Input Module. As a vital component of the renowned POINT I/O series by Rockwell Automation, this module is meticulously engineered to deliver 16 high-performance digital input channels. It ensures reliable data transmission and precise control across a wide spectrum of industrial applications, making it an indispensable asset for modern manufacturing and process environments. The 1797-IBN16 stands out for its exceptional compatibility, effortlessly integrating with leading Allen-Bradley control systems such as ControlLogix and CompactLogix, thus simplifying the connection of critical sensors, switches, and other field devices.

Designed for demanding industrial settings, the 1797-IBN16 module offers unparalleled flexibility, supporting both sourcing and sinking digital inputs. Its robust construction, coupled with advanced diagnostic capabilities, guarantees uninterrupted operation and quick troubleshooting. This module is not just a component; it's a foundation for building scalable, efficient, and highly responsive automation solutions. Invest in the 1797-IBN16 to elevate your system's performance and reliability, ensuring your operations run smoothly and effectively.

Key Features

• 16 Versatile Digital Inputs: Equipped with 16 independent channels, this module supports both sourcing and sinking digital inputs, providing maximum compatibility with diverse industrial sensors and field devices for flexible application design.
• Wide Operating Voltage Range: Operates efficiently within a broad 10-30V DC input voltage range, ensuring seamless integration and compatibility with a vast array of industrial equipment and power supplies.
• Superior Electrical Isolation: Features 500V RMS isolation between channels and channel-to-ground, offering robust protection against electrical interference and noise, thereby enhancing system stability and data integrity.
• Space-Saving Compact Design: Its optimized and compact form factor allows for efficient utilization of panel space, simplifying installation in control cabinets and making it ideal for systems where space is at a premium.
• Integrated Diagnostics LED Indicators: Each input channel is accompanied by an LED status indicator, enabling rapid visual diagnostics and simplifying troubleshooting by allowing operators to quickly monitor system health and pinpoint issues.
• Seamless Allen-Bradley Integration: As a core component of the POINT I/O system, it effortlessly integrates with ControlLogix and CompactLogix programmable automation controllers, facilitating scalable and high-performance industrial automation solutions.
• Robust Industrial Certifications: Certified with UL, CE, CSA, and RoHS compliance, guaranteeing adherence to stringent safety, quality, and environmental standards for reliable operation in global industrial environments.

Technical Specifications

• Part Number: 1797-IBN16
• Module Type: 16-Point Digital Input Module
• Input Voltage Range: 24V DC nominal
• Input Current: 3-7 mA per point
• Input Type: Sourcing or sinking digital inputs (configurable)
• Operating Voltage Range: 10-30V DC
• Isolation: 500V RMS channel-to-channel and channel-to-ground
• Power Consumption: 3.3W max
• Dimensions: 4.8 x 3.3 x 1.5 in. (121 x 84 x 38 mm)
• Weight: 0.4 lbs (0.18 kg)
• Operating Temperature Range: 0°C to 60°C (32°F to 140°F)
• Storage Temperature Range: -40°C to 85°C (32°F to 185°F)
• Certifications: UL, CE, CSA, RoHS compliant
• Mounting: Panel mount or DIN rail

Applications

• Advanced Industrial Automation: Connects a broad array of sensors, switches, and other critical field devices directly to Allen-Bradley control systems, underpinning sophisticated automated manufacturing processes and ensuring precise operational control.
• Integrated Control Systems: An essential component for ControlLogix and CompactLogix systems, providing reliable, real-time data input crucial for accurate monitoring, efficient control, and optimized decision-making within complex industrial environments.
• Real-time Process Control: Facilitates the gathering of vital digital input from sensors in process control applications, enabling dynamic, real-time adjustments and monitoring to maintain product quality and operational efficiency.
• Enhanced Machine Safety Systems: Plays a pivotal role in machine safety applications by interfacing with emergency stop buttons, critical limit switches, and safety interlocks, significantly contributing to a secure and compliant operational environment.
• Optimized Factory Automation: Elevates the capabilities of factory automation systems by enabling precise and accurate control over connected devices and processes, leading to increased productivity, reduced downtime, and greater operational flexibility.

Why Choose This Model?

• Unmatched Reliability: Engineered to withstand harsh industrial environments, offering consistent and dependable performance for critical applications.
• Seamless Compatibility: Designed for effortless integration with existing Allen-Bradley ControlLogix and CompactLogix systems, minimizing installation complexities and maximizing system synergy.
• Future-Proof Your Operations: Invest in a module that is part of a scalable and flexible system, allowing for easy expansion and adaptation to evolving industrial needs.
• Diagnostic Clarity: Built-in LED indicators provide immediate visual feedback, drastically reducing troubleshooting time and enhancing operational efficiency.
• Compact Efficiency: Its small footprint allows for maximum utilization of control panel space, making it an ideal choice for compact or retrofitted systems without compromising functionality.

Order Now

Elevate your industrial automation capabilities with the Allen-Bradley 1797-IBN16 POINT I/O 16-Point Digital Input Module. Experience the difference that precision, reliability, and seamless integration can make in your operations. For more advanced communication solutions, explore our extensive range of Allen-Bradley ControlNet EX Communication Modules, designed for high-speed and dependable industrial networking.
