Allen-Bradley 1769-L30ER-NSE

Overview

The Allen-Bradley 1769-L30ER-NSE is a high-performance CompactLogix 5370 L3 Ethernet controller engineered for demanding industrial automation applications. This versatile controller boasts 1MB of user memory and features dual Ethernet/IP ports with integrated Device Level Ring (DLR) support, ensuring resilient network communication. Designed for flexibility, this specific model operates without a supercapacitor for the real-time clock (RTC), offering a cost-effective solution while maintaining essential functionalities. It readily accommodates an SD card of up to 2GB, perfect for critical data logging, program storage, and easy firmware updates. Ideal for mid-range applications requiring robust control and seamless Ethernet integration, the 1769-L30ER-NSE delivers exceptional reliability and efficiency.

Key Features

• Optimized Memory: Equipped with 1MB of user memory to handle complex applications and efficient data processing.
• Redundant Ethernet/IP: Dual Ethernet/IP ports with embedded DLR support provide enhanced network reliability and uptime.
• Extensive Networking: Supports up to 16 Ethernet/IP nodes, facilitating comprehensive communication across your system.
• Flexible I/O Expansion: Allows for expansion with up to 8 Compact I/O (1769) modules, adapting to diverse application needs.
• Convenient Programming: Features a dedicated USB port for straightforward programming and firmware downloading.
• SD Card Versatility: Supports up to a 2GB SD card for reliable program backup, data logging, and efficient firmware updates on the go.
• Compact & Modular Design: Its small footprint and modular nature enable flexible installation in varied industrial environments.

Technical Specifications

• Manufacturer: Allen-Bradley / Rockwell Automation
• Part Number: 1769-L30ER-NSE
• Controller Family: CompactLogix 5370 L3
• User Memory: 1MB
• EtherNet/IP Ports: 2 (10/100 Mbps, with DLR support)
• USB Port: 1 (Type B for programming and configuration)
• I/O Expansion: Supports up to 8 local 1769 I/O modules
• EtherNet/IP Nodes: Up to 16 supported devices
• SD Card Support: Up to 2GB (for program and data storage, firmware updates)
• RTC: No supercapacitor (requires battery or external time source for timekeeping)
• Power Supply Current (5V DC): 800 mA
• Mounting Options: Versatile DIN rail or panel mount for streamlined integration
• Operating Temperature: 0 to 60 °C (32 to 140 °F)
• Dimensions (HxWxD): 118 mm x 87 mm x 87 mm (4.65 in x 3.43 in x 3.43 in)
• Weight: Approximately 0.5 kg (1.1 lbs)
• Certifications: UL, CE, CSA compliant for global industrial standards

Applications

• Advanced Machine Automation: Ideal for controlling complex machinery and motion systems where precise and reliable control is paramount.
• Process Control Systems: Excellently suited for process control applications demanding robust Ethernet/IP communication capability.
• Distributed Control Architectures: Perfect for industrial automation setups featuring multiple EtherNet/IP nodes requiring synchronized operation.
• Data-Intensive Operations: Highly capable for applications that benefit from extensive data logging or program storage via SD card for analysis and record-keeping.
• Mid-Range System Integration: Optimally designed for mid-sized industrial systems seeking a powerful yet compact and cost-effective automation solution.

Why Choose This Model?

• Unrivaled Network Resilience: The dual Ethernet/IP ports with DLR support provide critical network redundancy, minimizing downtime and ensuring continuous operation in challenging industrial environments.
• Data Management Made Easy: With support for a 2GB SD card, this controller simplifies program backup, data logging, and firmware updates, enhancing operational efficiency and data security.
• Space-Saving & Adaptable: Its compact and modular form factor allows for flexible installation in control cabinets with limited space, making it suitable for a wide range of applications.
• Cost-Effective Performance: By omitting the RTC supercapacitor, the 1769-L30ER-NSE offers a powerful and feature-rich solution at a more budget-friendly price point without compromising essential control capabilities.
• Seamless Integration: Fully compatible with Rockwell Automation's Studio 5000 Logix Designer software, ensuring a streamlined development and deployment experience for engineers.
• Proven Allen-Bradley Reliability: Benefit from the renowned quality and trustworthiness of Allen-Bradley products, ensuring long-term stable performance and readily available global support.

Order Now

Elevate your industrial automation with the Allen-Bradley 1769-L30ER-NSE CompactLogix L3 Ethernet controller. This robust and versatile controller is readily available and ships worldwide, bringing powerful and reliable control to your operations. For further exploration of our comprehensive range, we invite you to return to our CompactLogix Controllers main category to compare models and specifications. Additionally, delve into our complete selection of industrial automation solutions by visiting our Allen-Bradley Industrial Automation Products master category, where you'll find controllers, drives, motors, HMIs, and essential accessories tailored to meet every industrial demand.
