Allen-Bradley 1756-OG16

Overview

Elevate your industrial automation capabilities with the Allen-Bradley 1756-OG16 TTL Output Module, a prime solution for precise digital control within your ControlLogix system. This robust module delivers 16 independent low-true digital outputs, operating flawlessly at a 0–5V DC logic level. Engineered with a convenient 20-pin connector, the 1756-OG16 is meticulously designed to facilitate rapid and dependable switching, making it an indispensable asset for high-speed digital applications across a broad spectrum of industrial environments.

Optimized for seamless integration, the 1756-OG16 excels at driving logic-level inputs on various programmable logic controllers (PLCs), advanced sensors, and a myriad of other TTL-compatible devices. Experience unparalleled precision and consistent digital output performance, ensuring your critical control processes operate with maximum efficiency and reliability.

Key Features

• 16 High-Performance TTL Digital Outputs: Provides ample connectivity for diverse control requirements.
• Precise 0–5V DC Logic Level: Ensures compatibility and reliable signaling with TTL-sensitive equipment.
• Low True (Sinking) Logic: Offers versatile control options for various industrial setups.
• 20-Pin Connector Design: Facilitates secure and straightforward installation within your ControlLogix chassis.
• Exceptional High-Speed Switching: Ideal for time-critical digital control applications requiring rapid response.
• Seamless ControlLogix Backplane Integration: Guarantees full compatibility and efficient communication within your existing system.
• Robust Channel-to-Backplane Isolation: Enhances system reliability and protects against electrical interference.

Technical Specifications

The Allen-Bradley 1756-OG16 is engineered to meet rigorous industrial standards, providing reliable performance:

• Model: 1756-OG16
• Output Channels: 16 individual channels
• Output Voltage: 0–5V DC (TTL logic level)
• Logic Type: Low True (Sinking)
• Connector Type: 20-pin
• Backplane Current (5.1V): Approximately 250 mA
• Backplane Current (24V): Approximately 100 mA
• Isolation: Channel-to-Backplane
• Operating Temperature: 0°C to +60°C (32°F to 140°F)
• Mounting: Standard ControlLogix chassis slot

Applications

The versatility and high performance of the 1756-OG16 make it suitable for a wide array of demanding industrial applications:

• Advanced High-Speed Logic Control: Perfect for integrating with a variety of TTL-compatible equipment and systems.
• Precision Sensor & Signal Triggering: Provides reliable low voltage digital outputs for critical sensing tasks.
• Automated Electronics Testing Systems: Delivers consistent and accurate TTL pulse generation for quality control.
• Robotics & Complex Automation: Ensures accurate, high-speed signal control for intricate robotic movements and automated processes.
• Process Control Systems: Manages discrete output signals for various valves, indicators, and actuators.

Why Choose the 1756-OG16?

• Broad Device Compatibility: Offers standard TTL output, ensuring seamless integration with a vast range of industrial devices and systems.
• Optimized for Speed: Engineered for high-speed switching, crucial for time-critical processes where rapid response is paramount.
• Space-Saving Design: Its compact 16-point configuration with a 20-pin connector maximizes panel space efficiency.
• Unmatched ControlLogix Integration: Enjoy effortless setup and reliable performance within your existing Allen-Bradley ControlLogix architecture.
• Global Availability & Support: In stock and ready to ship worldwide, backed by reputable industrial automation expertise.
• Proven Allen-Bradley Reliability: Invest in a product from a trusted leader in industrial automation, ensuring long-term durability and performance.

Order Now

Ready to enhance your control system's precision and speed? The Allen-Bradley 1756-OG16 TTL Output Module is in stock and available for immediate worldwide shipping. Don't compromise on performance—invest in a solution that delivers consistent, high-speed digital control.
