Allen-Bradley 150-A68NB

Overview

Elevate your industrial automation with the Allen-Bradley 150-A68NB SMC-3, a high-performance 3-wire, open-type solid-state motor controller engineered for seamless motor starting and stopping. Designed for robust applications, this controller boasts an 85A current capacity and is perfectly suited for 480V 3-phase systems, making it an ideal choice for a diverse range of medium-sized motor operations requiring precision and reliability. Its flexible control voltage range of 100-240V AC ensures versatile integration into various industrial environments. The SMC-3 series is renowned for its exceptional performance, integrating critical features like overload protection, smooth soft start, and controlled stop functionalities. These innovations significantly reduce mechanical stress and wear on your equipment, ensuring smoother operational transitions and extending the lifespan of your motors. By eliminating the necessity for traditional contactors and overload relays, the 150-A68NB streamlines your system design, reduces complexity, and boosts overall operational efficiency.

Key Features

• 85A Current Capacity: Expertly handles motors up to 85 amps, making it suitable for a wide array of medium-power industrial applications.
• 480V 3-Phase Compatibility: Optimized for use within demanding 480V 3-phase power systems, ensuring broad applicability across many industrial setups.
• Versatile Control Voltage: Operates efficiently with a 100-240V AC control voltage range, offering exceptional flexibility for diverse electrical requirements.
• Open Type Design: Facilitates optimal ventilation and cooling, making it perfect for environments where thermal management is critical during continuous operation.
• Advanced Solid-State Technology: Delivers superior motor control with integrated soft start and stop capabilities, significantly minimizing mechanical wear and ensuring consistently smooth operation.
• Integrated Overload Protection: Safeguards your motors against excessive current, thereby enhancing their longevity and reinforcing the reliability of your entire motor system.
• Reduced Mechanical Wear: Eliminates the need for external contactors and overload relays, leading to a substantial decrease in mechanical wear and tear on your motor control infrastructure.

Technical Specifications

• Product Series: Allen-Bradley SMC-3
• Model Number: 150-A68NB
• Controller Type: 3-Wire, Open Type, Solid-State Motor Controller
• Current Capacity: 85 Amps
• System Voltage: 480V AC, 3-Phase
• Control Voltage: 100-240V AC
• Protection Features: Overload Protection
• Starting/Stopping Features: Soft Start, Soft Stop
• Mounting: Open Type (suitable for panel mounting within an enclosure)
• Application Suitability: Industrial Automation, Motor Control, HVAC, Material Handling
• Certifications: Consult Allen-Bradley documentation for specific regional and industry certifications.

Applications

• Conveyor Systems: Provides precise and gentle control for conveyor belts, reducing product damage and mechanical stress.
• Pumps & Fans: Ideal for controlling industrial pumps and fans, ensuring efficient operation and extended equipment life.
• Compressor Systems: Optimizes the start-up and shut-down of compressors, minimizing wear and improving energy efficiency.
• HVAC Systems: A staple in heating, ventilation, and air conditioning applications for reliable control of fans, pumps, and other critical components.
• Material Handling: Enhances the performance and longevity of automated machinery in material handling processes.
• General Industrial Automation: Applicable across a broad spectrum of industrial environments where smooth, controlled motor operation is paramount.

Why Choose This Model?

• Enhanced Motor Lifespan: The solid-state design and soft start/stop capabilities significantly reduce mechanical shock, preserving your motors and extending their operational life.
• Optimized Energy Consumption: By controlling motor acceleration and deceleration, the SMC-3 minimizes start-up current surges, leading to noticeable energy savings.
• Simplified System Design: This all-in-one solid-state controller eliminates the need for separate contactors and overload relays, simplifying wiring and reducing installation time.
• Robust Industrial Performance: Built with Allen-Bradley's renowned quality, the 150-A68NB is designed for continuous, reliable operation in demanding industrial settings.
• Versatile Integration: Its wide voltage compatibility and robust features ensure it can be seamlessly integrated into a multitude of existing and new industrial applications.
• Reduced Downtime: With its integrated protection features and reliable operation, this controller helps minimize unexpected breakdowns and maintenance, keeping your operations running smoothly.

Order Now

Upgrade your motor control systems with the Allen-Bradley 150-A68NB SMC-3 Solid-State Motor Controller. Experience unparalleled reliability, efficiency, and extended equipment life. For technical support or to place an order, contact our sales team today!
