Allen-Bradley 140G-G6C3-C30

Overview

The Allen-Bradley 140G-G6C3-C30 is a top-tier 3-pole molded case circuit breaker (MCCB) from the renowned 140G G-frame series, engineered to deliver superior circuit protection in the most demanding commercial and industrial environments. Rated at 600 amps with a reliable thermal-magnetic trip unit, this MCCB is your go-to solution for safeguarding electrical systems against damaging overloads and short circuits. Its robust design ensures consistent performance and compliance with stringent global standards like UL 489 and IEC 60947-2, making it a versatile choice for power distribution panels, motor control centers, and various other critical applications. Experience the unparalleled quality and durability that only Allen-Bradley can provide.

Key Features

• Robust 600 Amp Protection: Reliably safeguards circuits from overcurrents and short circuits.
• G-Frame Design: Compact and efficient footprint, ideal for space-conscious installations.
• Thermal-Magnetic Trip Unit: Provides dependable and fixed protection against both overloads and short circuits.
• High Interrupting Capacity: 35 kA @ 480V AC ensures safety and reliability in high-fault current scenarios.
• 3-Pole Configuration: Optimal for three-phase electrical systems, offering comprehensive protection.
• Global Standards Compliance: Meets UL 489 and IEC 60947-2 for worldwide applicability and safety.
• Versatile Voltage Rating: Operates effectively up to 600V AC, suitable for diverse power systems.

Technical Specifications

• Catalog Number: 140G-G6C3-C30
• Frame Size: G-frame
• Rated Current: 600 A
• Number of Poles: 3
• Trip Unit Type: Thermal-magnetic (fixed)
• Interrupting Capacity:
  • 35 kA @ 480V AC
  • 18 kA @ 600V AC
• Voltage Rating: Up to 600V AC
• Frequency: 50/60 Hz
• Mounting Type: Fixed
• Standards Compliance: UL 489, IEC 60947-2
• Operating Temperature: -25°C to +70°C
• Terminal Type: Line and load lugs (varies by configuration)
• Certifications: CE, UL, CSA
• Dimensions: Approx. 275 x 105 x 120 mm (HxWxD, varies by version)

Applications

• Industrial Machinery: Protects critical equipment and ensures operational continuity.
• Power Distribution Panels: Essential for safe and efficient power delivery within facilities.
• Motor Control Centers (MCCs): Provides vital protection for motor circuits, preventing damage and downtime.
• HVAC Systems: Guarantees reliable operation and safety for heating, ventilation, and air conditioning units.
• Commercial Buildings: Ideal for general power distribution in offices, retail, and public spaces.
• Data Centers: Safeguards sensitive electronic equipment from electrical faults, ensuring uptime.

Why Choose This Model?

• Unmatched Reliability: Allen-Bradley's reputation for quality ensures long-lasting and dependable circuit protection.
• Superior Performance: High interrupting capacity of 35kA at 480V AC effectively handles fault currents, minimizing damage.
• Global Compliance: UL and IEC certifications mean this breaker is suitable for a wide range of international applications.
• Space-Saving Design: The compact G-frame facilitates easier integration into existing panels with limited space.
• Heavy-Duty Protection: The 600A rating is perfectly suited for demanding applications with high current requirements.
• Enhanced Safety: Thermal-magnetic trip unit offers comprehensive protection against both overloads and short circuits, securing personnel and assets.

Order Now

Secure your electrical infrastructure with the premium protection of the Allen-Bradley 140G-G6C3-C30 molded case circuit breaker. This essential component is readily available and poised for immediate worldwide shipping. Don't compromise on safety and reliability – invest in Allen-Bradley's proven expertise.
