ABB DI810 | 3BSE008508R1

Overview

The ABB DI810, identified by product ID 3BSE008508R1, is a high-performance 16-channel digital input module meticulously engineered within the S800 I/O series for demanding industrial automation environments. This robust module operates at 24V DC and is designed to provide reliable data acquisition from a multitude of sensors and switches, acting as a crucial interface in complex control systems. A key differentiating feature is its innovative design incorporating two independently isolated groups of 8 inputs each, which significantly bolsters system reliability and safeguards connected equipment against electrical disturbances. Compatible with a wide array of Module Termination Units (MTUs) including TU810, TU812, TU814, TU818, TU830, TU833, TU838, and TU850, the DI810 offers unparalleled flexibility for integration into existing or new S800 I/O infrastructures. Its compact form factor and DIN rail mounting capability (via MTU) ensure a streamlined installation process, making it an excellent choice for optimizing space in control cabinets while delivering exceptional performance.

Key Features

• High-Density Input: Provides 16 digital input channels for comprehensive signal monitoring.
• Input Voltage: Operates efficiently with a standard 24V DC input, suitable for most industrial applications.
• Advanced Isolation: Features 2 distinct groups of 8 isolated channels, enhancing system resilience and safety.
• S800 I/O Series Integration: Part of the renowned ABB S800 I/O family, ensuring seamless compatibility and performance.
• Diagnostic Capabilities: Equipped with individual status LEDs for each channel, enabling quick and easy fault diagnosis.
• Flexible Connection: Designed for use with various Module Termination Units (MTUs) such as TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU850, offering versatile connection options.
• Space-Saving Mounting: Effortlessly mounts on a DIN rail when paired with a compatible MTU.

Technical Specifications

• Model Number: DI810
• Product ID: 3BSE008508R1
• Nominal Voltage Level: 24V DC
• Total Channels: 16 digital input channels, intelligently organized into 2 isolated groups of 8.
• Input Type: Supports both Sink and Source input configurations for broad compatibility.
• Input Delay: User-configurable to meet specific application timing requirements.
• Indicators: LED indicators for per-channel status, enhancing operational visibility.
• Compatible Module Termination Units (MTUs): TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU850.
• Operating Temperature Range: -20°C to +55°C, ensuring reliable operation in diverse industrial environments.
• Storage Temperature Range: -40°C to +70°C, suitable for varied storage conditions.
• Mounting Method: Secure DIN rail mounting achieved via a compatible MTU.
• Protection Class: IP20, providing protection against solid objects larger than 12.5mm.
• Certifications: Complies with CE, UL, and RoHS standards, affirming adherence to international quality and safety regulations.

Applications

• Industrial Automation: Serves as a vital component for collecting digital signals from a myriad of sensors, limit switches, and control devices, facilitating precise automation sequences.
• Process Control Systems: Integrates seamlessly with Distributed Control Systems (DCS) and Programmable Logic Controllers (PLCs) for efficient real-time input monitoring and command execution in critical processes.
• Power Plants & Utilities: Indispensable in safety and control panels, providing reliable input data for monitoring equipment status and ensuring safe operational parameters.
• Manufacturing Plants: Crucial for real-time equipment feedback and status tracking on production lines, enabling proactive maintenance and optimizing manufacturing workflows.
• Building Management Systems: Can be employed for monitoring various digital inputs within large-scale building automation, such as door contact states, alarm triggers, and utility status.

Why Choose This Model?

The ABB DI810 (3BSE008508R1) stands out as a superior choice for industrial automation needs due to its blend of advanced features and robust design. Its high-density 16-channel input capability within a compact footprint allows for efficient use of cabinet space without compromising on signal acquisition. The paramount feature of two independent groups of 8 electrically isolated channels not only significantly enhances the safety of your system by preventing ground loops and voltage spikes but also ensures an unparalleled level of data integrity. This module's broad compatibility with multiple Module Termination Units (MTUs) provides system integrators with exceptional flexibility during installation and subsequent upgrades. As a proud member of the acclaimed ABB S800 I/O family, the DI810 guarantees seamless integration, exceptional reliability, and consistent performance within existing or new ABB control architectures. Choosing the DI810 means investing in a proven, high-quality component that bolsters the efficiency, safety, and longevity of your industrial and process control operations.

Order Now

Secure your ABB DI810 16-channel 24V DC Digital Input Module (3BSE008508R1) today and elevate the performance and reliability of your industrial automation systems. This essential component is available for immediate worldwide shipping, ensuring that your critical projects can proceed without delay. Experience the peace of mind that comes with ABB's renowned quality and global support network.
